Sindeice flake ice evaporator machine 2T 24h Sindeice flake ice evaporator machine 2T 24h Sindeice flake ice evaporator machine 2T 24h

Sindeice flake ice evaporator machine 2T 24h

FOB Price:
US 6000-8700 / Unit
Min.Order Quantity:
1 Unit/Units
Supply Ability:
100 Unit/Units per Month
Port:
Shenzhen Port
Place of Origin:
Guangdong, China (Mainland)
Payment Terms:
L/C,T/T,Western Union
Brand:
Sindeice
Products Model:
SDAF-2TR4
Share:
  • Products Details
  • Company Profile

Quick Details

  • Brand Name: Sindeice

    Model Number: SDAF-2TR4

    Place of Origin: Guangdong, China (Mainland)

Packaging & Delivery

  • Packaging Details: standard plywoode case
  • Delivery Detail: 30 working days after deposited

Specifications





Sindeice Stainless Steel 304 flake ice machine 2T/24h



Company Information

SHENZHEN SINDEICE SYSTEMS CO., LTD (Sindeice for short) is a professional manufacturer of ice machines, who has a set of research, design, production, installation, sale and after-sales service. We got a number of experienced experts who engaged in refrigeration and ice machine for many years. With the use of best technology of ice machine and innovative solutions, Sindeice manufactures Flake ice machine, Tube ice machine, Block ice machine, Ice flaker evaporator, Containerized ice plant. Daily capacities are available from 300 kg to 100,000 kg.



Sindeice is sticking to the notion of “great virtue,social commitment”, and the management policy of “integrity, diligence, innovation and mutual benefit”.Sindeice strives to enter into international market.







Product Description

Characteristics of  Flake Ice

A mechanical freezing system, however advanced it is, can provide only a low temperature, while cannot provide a humid environment. This disadvantage will dry the surface of, dewater or frostbite the fresh and live commodities. Only ice will provide a perfect cooling and watery environment to keep the fresh and live commodities in an ideal status. Flake ice is widely used in seafood and fresh meat preservation and display in supermarkets. As flake ice is dry and smooth, it will not scratch the fresh and live commodities, in the same time, it will maintain good ventilation. That will ensure the original taste of the commodities and prevent loss caused by dewatering of the commodities.

Large contacting area and quick freezing
         As flake ice is in a flat shape, it has a large contacting area compared to ice of the other types. The larger the contacting area, the more effective the freezing becomes. For example, the minimum area of 1000 Kg flake ice is 1,579 square meters, while ice of same quantity in the other types provides only 395 to 1294 square meters contacting area. So the freezing (cooling) effectiveness of flake ice will be 2 – 5 times that of tube ice or cube ice.

Outstanding Food Preservation
       Flake ice is dry, soft and flat. These characteristics will protect the packaged food during the packing and refrigeration process. Its flat pattern will minimize the possibility of damaging the refrigerated commodities.

Complete Mixing
       As flake ice has a gigantic contacting area and the heat ejection happens quickly, flake ice melts quickly into water, taking the heat away and intensifying humidity of the mixture.


With the development of society, Ice-making machine have been used more and more in various field to achieve their processing.



,  Supermarkets

 SINDEICE plate ice is pure in color, luster and good ventilation. It could be used for keep sea food or meat fresh, and show a good view. The smooth and dry surface of plate ice can avoid scratching the food.



2, Meat processing

Plate ice is widely used in the meat processing. For example, in the processing of making sausage, the high temperature, made by the machine, changes the color and taste of meat. It also brings more bacteria. But if plate ice was added into the ingredients, the color and taste of sausage remains well, and less bacteria.



3,Aquatic Product Processing

 For ice can provide adequate moisture, and reduce the temperature, it is widely used in the aquatic product processing, such as ocean-fishing, storage, transport and processing . Mechanical refrigeration systems can only provide cold temperature, but not adequate moisture, it makes the surface of aquatic product air-dry, dehydrated, even frozen. Ice can make the perfect cold environment, keeping aquatic product wet and fresh. Meanwhile, melting ice water can clean the surface of product as well, it takes bacteria and smell away.



4, Poultry Slaughtering House

 Food export enterprises have strict standard for each single process. Spiral cooling tank water temperature should be 0℃-4℃. Cold water machine can’t meet the requirement. So lot of ice should be added into the spiral cooling tank to keep water temperature  0℃-4℃.



5, Dairy Food Processing

 During the process of yogurt fermentation, artificial refrigeration is used for keep the fermentation temperature under the normal, to control the time, humidity, maintain the biological activity of yogurt. Adding some dusty piece of ice is a good method.



6,Bio-pharmaceutical

 In the process of production of bio-pharmaceutical, large quantities of sanitary and clean ice can be added to control reactive temperature, maintain biological vitality and ensure product quality.



7, Ocean-going Fishing

 Flake ice machine has wider application in marine fisheries. Scaly ice is so unique to cold storage, transport, process and show seafood. Scaly ice is a practical and economic system to keep seafood fresh, wet and right temperature, without monitor. Scaly ice provide a perfect cold environment. The smooth and dry surface of plate ice can avoid scratching the food. Meanwhile, melting ice water can clean the surface of product as well, it takes bacteria and smell away.



8, Application of Concrete Cooling Projects

 Pouring construction of large dams and tall buildings around the world requires the use of temperature control of concrete. In the course of maintenance, large volume of concrete grouted temperature rise 25 degree, concreting volume expansion. But after the course of maintenance, large volume of concrete grouted cools down and reduces dwindles in size, usually leading to cracks in water dykes. Therefore, the initial grouting temperature of concrete should be low enough to ensure the highest temperature of concrete during maintenance does not exceed that determined by design units. Mixing ice and water ,or adding ice directly is the normal way to reduce the temperature. SINDEICE is experienced in the field of application of concrete cooling projects, and we can design concrete bathing plant with ice-making, storage, transport, according to different conditions.





Technical Data

*The technical data based on 25 ambient temp.18 water inlet temp.

*The evaporating temperature is -20.

*The condensing temperature is 40.

*Power supply: 3P / 380V / 50HZ 3P/220V/60HZ

*Refrigerant:R404a/R22/R507/R717

*Inner wall material: SUS304&Q345 Hard chromium plating



Model

SDE-2T

The evaporating emperature()

-20

The condensing temperature()

40

Daily output(Ton/24hrs)

2

Cooling capacity(kW)

11.6

Genaral power(kW)

8.06

Compressor Input(kW)

6.9

Reductor Power(kW)

0.37

Water Pump Power(kW)

0.09

Condenser Fan Power(kW)

0.68

Salt Water Pump Power(kW)

0.016

Noise(dBA)

65

Cooling Mode

Air cooling

Water inlet/drain pipe

1/2"

Dimension(mm)

1500*1100*1045

Weight(kg)

420





Component



Maintenance
To lengthen the lifetime of an ice machine and increase the efficiency for energy-saving purpose, a regular check on the ice machine is quite necessary. User is suggested to make a monthly/quarterly/yearly record of maintenance and servicing and a very detailed log of the damage servicing so that servicing personnel can properly trace the failure history during trouble shooting process.

Daily Maintenance
Start and Stop the machine as instructed in this manual;
Make a regular record of the parameters in operation daily;
Regular check on the Dryer Filter is necessary. If frost is found on the outlet of the Filter, that may mean jamming inside the Filter. This symptom is normally accompanied by low evaporating pressure and higher condensing water temperature.
Check if the refrigeration oil is normal. If there is lack of refrigeration oil, add more. And if the oil is dirty and goes bad, change it and clean the oil filter and change to a new filter core.
When there is lack of refrigerant, to prevent frequent turn-off of the machine, the capacity status should be set to a partial load. After refrigerant is filled, set the capacity status to full load.
Any failure occurrence should not go unnoticed. A thorough analysis should be done for the cause of failure. Make a thorough analysis of the failure may help with finding a solution to the problem. And notice the SINDEICE after-sale service department of the analysis that is done.

Regular Maintenance
Regular maintenance includes maintenance on a weekly/monthly/quarterly/yearly basis. User can refer to the following scientific maintenance scheme and carry it out in a strict manner. That may help with prevention of failures in a substantially crucial way.

Weekly maintenance
Check and make an analysis of the parameters of ice machine in operation.

Monthly maintenance
Check and make an analysis of the record of parameters of ice machine in operation;
Check the bolts fastening the power wires are always tight;
Check and confirm there is no noise on all moving parts of the ice machine, and there is no abnormality in operation;
Check the water system is working properly;
Check the Compressor’s oil heater is working properly;
Check the High & Low Pressure is normal;
Check the operation current of compressors and motors is normal; check the resistance is normal. If the resistance is lower than 5 MΩ, stop the machine immediately.
Check the water tank/freezing surface/ice storage bin/water distributing tubes/condenser’s fins regularly and clean the dust and dirty things.

Our Services

Installation:

1). Installing by the user: we will tested and install well the machine before shipment, all necessary spare parts and operation manual are provided to guide the installation.


2). Installing by SINDEICE engineers:

 (1) We can send our engineer to assist the installation and provide technical support and train your workers. The end-user provide accommodation and round-trip ticket for our engineer.



(2) Before our engineer arrived in your site, the installation place, electricity, water and installation tools should be ready. Meanwhile, we will provide you a Tool List with the machine when delivery.
