Sanhua electric expansion valve EEV controller SEC601

Sanhua electric expansion valve EEV controller SEC601

FOB Price:

US 68.96-79.1 / Piece

Min.Order Quantity:

1 Piece/Pieces

Supply Ability:

100000 Piece/Pieces per Month

Port:

Shanghai, Ningbo, Gungzhou, as your requirements

Place of Origin:

Zhejiang, China (Mainland)

Payment Terms:

L/C,D/A,D/P,T/T,Western Union,MoneyGram,Paypal, Trade Assurance

Brand:

SANHUA

Products Model:

SEC-601

Products Details
Company Profile

Quick Details

Brand Name: SANHUA

Model Number: SEC-601

Place of Origin: Zhejiang, China (Mainland)

Packaging & Delivery

Packaging Details: Single Packaged. 1pcs/box.
Delivery Detail: 10-15days after confirmed

Specifications

Sanhua electric expansion valve EEV controller SEC601

Product Description

Electronic expansion valve controller is applicable for cooling systems such as room air conditioners, commercial air conditioners and freezers which is the core component for refrigerant flow control.

Features of EEV controller:

1. Smaller installation space:Lower height, smaller size, lighter weight

1,Adopting sharing PCB design (4 models), applicable for detections of three temperature sensors or one temperature and one pressure sensor

2,Applicable for split or packaged unit,either cooling or both cooling and heating with various voltage

3,Applicable for all Sanhua electronic expansion valves allowing trouble-free seclection and compatibility for customers

4,The controller is equipped with a whole set of advanced system control solutions for which parameters could be adjusted according to users’ requirements

Specifications

Items	Description
Dimension(WHD)	7211429mm
Power supply	24Vac+10%/-15%,50/60Hz&24Vdc
Display	FND, LED
Connection	XHP
Input	1P Press. sensor input
	1P Temp. sensor input
	1P Digital input
Output	1P Relay output(250Vac/30Vdc/5A)
Output	1P EEV(Unipolar) output
Operation	Temp. -10~50℃, Humidity≤90%RH
Storage	Temp. -20~60℃, Humidity≤90%RH
