FY pneumatic drum pump explosion proof barrel pump

FY pneumatic drum pump explosion proof barrel pump

FOB Price:

USD 300-3000 / Unit

Min.Order Quantity:

1 Unit

Supply Ability:

1000 Unit per Month

Port:

Shanghai

Place of Origin:

MADE IN CHINA

Payment Terms:

T/T

Brand:

kenshine-pump

Products Model:

FY3.2T-2

Products Details
Company Profile

Quick Details

Brand Name: kenshine-pump

Model Number: FY3.2T-2

Place of Origin: MADE IN CHINA

Packaging & Delivery

Packaging Details: plywood case
Delivery Detail: 7 days

Specifications

FY pneumatic pulp pump (short for pulp pump, also known as leather pulp spray pump, high viscosity pulp pump, pneumatic slurry pump, pneumatic paint pump, pneumatic plug pump, pneumatic explosion proof barrel pump)

FY pneumatic pulp pumps are widely used in the fields such as leather, textile, printing and dyeing, PVC, wallpaper, coating, color painting board, color steel tile, food, medicine, chemicals, spray painting, spray dyeing, film aluminum plating, glass steel, PVC steel, petroleum, mining, shipping, automobile, electrical equipment refrigeration etc. FY pneumatic pulp /slurry pump can be also suitable to transport high viscosity liquid pulp with 50 thousand CPS/25 Celsius degree, having the functions such as corrosion resistance, anti-sediment, low noise, energy saving etc. It is an ideal feeding facility.

FY stainless steel pneumatic glue pump adopts the function of pressure difference to make the piston move up and down and drive the guide piston to open and close, and play the role of material lifting. Adjust the flow rate and air pressure of the working gas to the pneumatic slurry pump to control and adjust the feed flow rate of the pneumatic slurry pump.

Model	FY0.8T	FY1.2T-1	FY1.2T-2	FY3.2T-1	FY3.2T-2	FY-5.0T
Specification (mm)	φ100×H1450	φ100×H1450	φ100×H1400	φ120×H1600	φ120×H1500	φ150×H1680
Flow (L/min)	10-20	10-30	10-30	20-70	15-50	30-100
Max.grain Dia.(mm)	Φ0.8	φ1.2	φ1.2	φ3	φ1.2	φ5
Head(m)	0-100	0-100	0-100	0-100	0-100	0-100
Max.viscosity (CPS/25℃)	120000	120000	120000	120000	120000	120000
inlet/outlet (mm)	51/32	60/32	55/32	72/38	55/32	88/50
Outlet connection(in)	1 ^1/4	1 ^1/4	1 ^1/4	1^1/2	1^1/2	2
Air connector (in)	3/8	3/8	3/8	3/8	3/8	3/8
Max.air pressure (kg/cm3)	10	10	10	10	10	10
Air pressure (MPa/min)	0.3-1.0	0.3-1.0	0.3-1.0	0.3-1.0	0.3-1.0	0.3-1.0
Outlet pressure (MPa)	0.3-1.0	0.3-1.0	0.3-1.0	0.3-1.0	0.3-1.0	0.3-1.0
cylinder pressure ratio	2:01	2∶1	2∶1	3∶1	4∶1	3∶1
air consumption (m3/min)	0.3-1.0	0.3-1.0	0.3-1.0	0.3-1.0	0.3-1.0	0.3-1.0
Size(cm3)	143×19×18	152×19×18	147×19×18	166×21×18	158×21×18	172×23×21
Weight(kg)	14	16	15	23	19	37
