2017 new design -25 degree C dc inverter evi air source heat pump water heater for floor heating radiator heating hot water

FOB Price:

US 1,800-1,900 / Unit

Min.Order Quantity:

1 Unit/Units

Supply Ability:

1000 Unit/Units per Month

Port:

Guangzhou

Place of Origin:

Guangdong, China (Mainland)

Payment Terms:

T/T

Brand:

DERON

Products Model:

DE-46W/CW

Products Details
Company Profile

Quick Details

Brand Name: DERON

Model Number: DE-46W/CW

Place of Origin: Guangdong, China (Mainland)

Packaging & Delivery

Packaging Details: complex fibre board or plywooden case
Delivery Detail: 25-30 working days

Specifications

2017 new design -25 degree C dc inverter evi air source heat pump water heater for floor heating radiator heating hot water

Model: DE-46W/CW

This series of air source EVI heat pump is is specially designed for house heating in chilly climate areas, it can be applied to sanitary hot water for bathroom or house heating for house where safe working at temp -25 deg.C to 45deg.C.

Model DE-46W/CW got the bidding of goverment leading house heating project in China Capital city, Beijing, 2016.

1)Operation range: -25°C~+45°Cambient temperature.

2)Hot water outlet range: 30°C~60°C

3)Power supply: 220V/1ph/50Hz.

4)Copeland brand EVI compressor with /R417a/R22 refrigerant.

5)Water flow switch is optional .

6)Adjustable defrosting according to different weather conditions (with four way valve inside).

7)Optional auxiliary electric heater control function is optional

8)Anti-freezing function to protect the circulation pump and water pipe connected to heat pump.

Model		DE-46W/CW
Power supply	V/Ph/Hz	220/1/50
1)Heating capacity	kW	15.4
1)Heating capacity	BTU	52545
Rated power input	kW	4.6
2)Heating capacity	kW	8.25
2)Heating capacity	BTU	28149
Rated power input	kW	3.57
Refrigerant		R22
Compressor	Type	Copeland
Fan	Qty	1
Required water flow rate	m3/h	1.7
Water connection		G1"
Max. current	A	26
Noise	dB (A)	≤60
Max. water outlet temp.	℃	60
Operation temp. range	℃	-25-45
Net weight	kg	175
Net size(L/W/H)	mm	955×505×1480
1)Heating by Ambient temp.: 7℃ and Water temp.(in /out): 40℃/45℃;
2)Heating by Ambient temp.: -12℃ and Water temp.(in /out): 40℃/45℃;
Above information just for your reference, Please subject to the nameplate on the unit.
Refrigerant is optional

1. We are a nationally high-tech company in China with technical cooperation with Germany, focusing on researching and producing environmental energy-saving heat pump units, which are mainly used in guesthouses, hotels, schools, offices, factories, hospitals and family villas.

2. Our company is among the earliest companies to establish the heat pump R&D center in China, and has our own heat pump laboratory, which lead to the breakthrough that the use of heat pump at -25 deg.C low temperature zone is possible. Moreover, we made it practical to test the air source, water source or ground source heat pumps.

Our company has set up our heat pump technology transfer center of Guangzhou Institute of Energy Conversion, Chinese Academy of Sciences and Sino-Germany Magnetically Levitated Heat Pump R&D Center. Our company is also the strategic partner of American Emerson Copland Company.

3. Our company has obtained the license of national industrial production. Our products have passed ISO9001 quality system, and gained national CCC compulsory certification, CE certificate of the EU, and TUV as well as SGS.

4. Deron is regarded as "Top Ten Heat Pump Water Heater Brands" in China and 2010 Asian Games Venues are equipped with Deron heat pump systems to provide hot water for athletes.
