Home > Products > Refrigeration Equipment > Water Chiller

Draft Glycol Chilling System Design Glycol Chiller Refrigeration System

FOB Price:

Get Latest Price

Min.Order Quantity:

1 Unit/Units

Supply Ability:

200 Unit/Units per Quarter

Port:

Qingdao, China

Place of Origin:

Shandong, China (Mainland)

Payment Terms:

Brand:

Mgreenbelt

Products Model:

MG-30CL(D)

Products Details
Company Profile

Quick Details

Brand Name: Mgreenbelt

Model Number: MG-30CL(D)

Place of Origin: Shandong, China (Mainland)

Packaging & Delivery

Packaging Details: Glycol cooling unit in plywood case.
Delivery Detail: 20 Working Days

Specifications

Draft Glycol Chilling System Design Glycol Chiller Refrigeration System

About Low Temperature Water Chiller
Adopt durable and stale original well-known hermetic scroll compressor. Electric and refrigeration components all adopt world brand. According to different industry requests, optional stainless steel and high head water pump available. Provide wide range changeable temperature, meeting 12-month cooling demands. Independent design, one compressor to one circuit, no interaction. Microprocessor control, easy to operate.

About Low Temperature Water Chiller

Adopt durable and stale original well-known hermetic scroll compressor.
Electric and refrigeration components all adopt world brand.
According to different industry requests, optional stainless steel and high head water pump available.
Provide wide range changeable temperature, meeting 12-month cooling demands.
Independent design, one compressor to one circuit, no interaction.
Microprocessor control, easy to operate.

30HP Propylene Glycol Cooling System Chiller Parameters
1. Outlet Cooling Water Temperature: 0 degree
2. Cooling Capacity: 67.0kW/20USRT/57620Kcal/h
3. Refrigerant: R407c, R22, R404a
4. Voltage: 220v/380v/415v/440v/460v/480v

30HP Propylene Glycol Cooling System Chiller Parameters

1. Outlet Cooling Water Temperature: 0 degree

2. Cooling Capacity: 67.0kW/20USRT/57620Kcal/h

3. Refrigerant: R407c, R22, R404a

4. Voltage: 220v/380v/415v/440v/460v/480v

Cooling Water Chiller Plant Services
1. Warranty: 14 Months.
2. Customerized accept.
3. All extral parts for the machine can be purchased by agent price from Mgreenbelt.
4. Technical support and after-sales service free of charge.
5. Professional technical team and Sales give troubleshooting procedures.
6. Door-to-door service if necessary.

Cooling Water Chiller Plant Services

1. Warranty: 14 Months.

2. Customerized accept.

3. All extral parts for the machine can be purchased by agent price from Mgreenbelt.

4. Technical support and after-sales service free of charge.

5. Professional technical team and Sales give troubleshooting procedures.

6. Door-to-door service if necessary.

19 Tons Chemical/Pharmaceutical Used Glycol Chiller Specification
Chiller Model		MG-30CL(D)
Outlet Cooling Water Temperature		0 degree celsius
Cooling Capacity	kW	67.0
Scroll Compressor	Type	Hermetic Scroll
	kW	26.1
	Quantity	3
Refrigerant Gas	Type	R407c, R22, R404a
Refrigerant Gas	Control	Expansion Valve
Evaporator	Type	Tank with Coils Shell and Tube Exchangers
	Cooling Water Flow (m3/h)	12.70
	Water Tank Capacity (L)	450
	Pipe Diameter	DN65
Condenser	Type	Air-Cooled
Condenser	Cooling Fan Motor (kW)	1.56
Glycol Chiller Pump	kW	1.5
Glycol Chiller Pump	Head (m)	20

Water Cooling Packaged Chiller Parts

High efficiency, low noise fans with integral condensers for reduce operating noise and increased efficiency features totally enclosed air over motors for long life.

Applications of Industrial Glycol Water Chiller

Diary: Cooling Milk
Food: Bakeries, Beverage, Breweries, Poultry, Yogurt Machines, Fermentating
Chemical: Brine Cooling, Chemical Process, Laboratory, Medical, Phasma Cooling, Oil Cooling
Construction: Cement Cooling, Cold Storage, Concrete Cooling, Die Casting Dough Mixing, HVAC

Industrial Water Chiller Plant

Contact: Lean

Mobile: 86-17686681006

Skype: lzchiller

E-mail: cnchiller(at)gmail.com

Contact freely for request of water chillers!

Established in the year 2003, we, " Mgreenbelt Machinery Co., Ltd," are engaged in manufacturing, exporting and supplying Chillers, Cooling Towers, Heat Exchangers and Components. Our range is appreciated by the clients based in various parts of China and world for its characteristics, such as robust structure, longer service life and high performance. The durable products are manufactured by experienced workers, using graded alloys and qualified electronic components. Further, for clients' covenience, we undertake the designing and turnkey projects for the devices.

At the sound manufacturing facility, we undertake the production of high performance machines. The quality controllers test the range, to ensure that it is in compliance with the degree of prevailing quality standards. Moreover, we also offer after sales services to ensure all the queries to be handled within the shortest time. We would like to grow and improve by anticipating consumers' needs, offering a better solution than competitiors and supporting customers to be confident of getting fast answers of requirement.

We have been successfully in offering machines to projects of Packaged Equipment and System, Automobile Components Producing System, Food Making, Bakery, etc. to clients from domestic, USA, Canada, Australia, Ecuador, Sudan, Russia, South Africa, Dubai, Israel, India, Philippine, Singapore, Vietnam, Thailand and Korea, etc.
