Electric Linear Actuator 30NM

FOB Price:

US 63-110 / Piece

Min.Order Quantity:

50 Piece/Pieces

Supply Ability:

1000 Piece/Pieces per Month

Port:

Shanghai

Place of Origin:

Shanghai, China (Mainland)

Payment Terms:

L/C,T/T,Western Union,MoneyGram

Brand:

CH-BA

Products Model:

AM/AF30-24

Products Details
Company Profile

Quick Details

Brand Name: CH-BA

Model Number: AM/AF30-24

Place of Origin: Shanghai, China (Mainland)

Packaging & Delivery

Packaging Details: Carton
Delivery Detail: Shipped in 7 days after payment

Specifications

The AM/AF series of electric damper actuators are used in ventilation, and air-conditioning (HVAC) applications. The AM series of electric damper actuators are modulating control actuators used with controls that provide an analog output of 0 to 10Vdc, 2 to 10Vdc or 4-20mA. The internal selector plug can be used to reverse the direction of action. The AF series of electric valve actuators are controlled by an on/off output.

Low power consumption

Position feedback by signal

Direct/reverse acting

4-20mA/0-10V/2-10V choice

Maintenance free

Quick and easy installation

No separate linkage required

Accurate valve positioning

Indicator Continuous Position Indicator

Manual Override Non-clutch design

Stall Protection Built-in thermal protection

TECHNICAL DATA

Actuator
Actuator	AF/AM
Output torque	10, 15, 20,30 40N.m
Power supply	AC/DC24V
Run time	About 120S
Operating power	5VA
Output angle	90°± 3°
ON/OFF control signal	1 wire or 2 wire control
Control signal	4(0)~20mA,or 0(2)~10V
Feedback signal	DC0 -10V
Installation position	Upright to horizontalNo upset
Protection class	IP54
Ambient conditions	- 10°C. to. +55°C 0..90% RH
Weight	1kg/1.6kg
Material	Flame-resistant Abs

Quality Testing

Package and Shipping

Sample Order	Order	OEM Order
Three work days	2 weeks	3 weeks

Port

Shanghai

♦ Specilizng in manufacturing products of HVAC for almost 10 years.

♦ Harsh process of production and strict testing system.

♦ High quality with competitive price.

♦ Delivery in time.

♦ Reply in 24 hours.
