Round Air Conditioning Ceiling Jet Nozzle Diffusers

FOB Price:

US 10-60 / Piece

Min.Order Quantity:

1 Piece/Pieces

Supply Ability:

50000 Piece/Pieces per Month

Port:

Tianjin

Place of Origin:

Tianjin, China (Mainland)

Payment Terms:

L/C,D/A,D/P,T/T,Western Union,MoneyGram,Paypal

Brand:

Products Model:

Products Details
Company Profile

Quick Details

Brand Name: HX

Model Number: CL

Place of Origin: Tianjin, China (Mainland)

Packaging & Delivery

Packaging Details: Standard carton and pallets for Round Air Conditioning Ceiling Jet Nozzle Diffusers
Delivery Detail: Shipped in 15 days after receiving the payment

Specifications

You May Like

Drum Type Diffuser Round Air Diffuser Double Deflection Air Grille

Product Description

Round Air Conditioning Ceiling Jet Nozzle Diffusers

The ball round ceiling diffuser consists of external frame and inner core, and the core part can be adjusted in 30 degree to change the air flow direction when the frame is fixed. The ball round ceiling diffuser is widely used in the place where there is a long distance between the air supply outlet and the people active area, such as music hall, cinemas, museums, etc.

Jet Nozzle Diffuser Picture

Specification

Jet Nozzle Diffuser Specification

Product	Jet Nozzle Diffuser
Material	Aluminum Alloy Sheet
Neck Size (mm)	100, 125, 150, 200,250,315,350,400,500,630mm
Addable accessories	Electric actuator, Air volume valve, Plenum chamber
Control	Manual or electric
Color	Powder coated --White RAL9010/9016
Features	1. Jet nozzle diffuser consists of a spherical discharge nozzle mounted in a housing and is complete with a front mounting flange and circular spigot for direct connection to a circular duct.
	2. The jet nozzle diffuser can be adjusted manually up to max 30 degree in any direction.
	3. The adjustment can be motorized with an electric actuator or a pneumatic actuator.
	4. The jet nozzle diffuser is suitable for long throw distances with optimum acoustic properties, preferably used for side areas of large room.
	5. Customers can hoose different spec to achieve the required throw distance and speed.

Pls confirm the neck size of adjustable jet nozzle diffuser so that we can manufacture the jet exhaust air grille air diffuser based on your requirements.

Jet Nozzle Diffuser Mounting

The ball jet nozzle diffuser can be mounted directly to the duct, plenum box or surface allows a flexible duct of standard dimensions to be coupled directly to each nozzle.

Details Display

Adjustable jet nozzle diffusers are made of high quality aluminum alloy, which can guarantee the long using life of the air diffusers.

CE Certificate

Air Diffuser Installation

Air grilles and air diffusers can be installed on the ceiling, side wall, etc.

Main Air Diffusers

There are various of air grilles and air diffusers to be chosen, and the air grilles can be customized on your request.

Company Information

HVAC ventilation products workshop---We have professional technician and workers to guarantee the products quality.

Trading Process

Packaging & Shipping

Different transportation modes can be chosen, such as by air , by sea, etc.

Our Services

1. We have professional technicians to provide advice on choosing models;

2. We have specialized foreign trade staff to offer best quotation for you;

3. We have experienced staff to provide installation guide for you;

4. We will choose the most economical mode of transport to save cost for you;

5. We will offer good after-sales service for you.

If interested in our Jet Nozzle Diffuser or other products, pls just contact us and we will quote a best price for you after receiving your inquiry.
