underfloor electric heating element with temperature controller

electric heating element with temperature controller

Electric Underfloor Heating Mat Electric Heated Floor Mat Electric Warm Floor Mat Infrared Heating Mat Radiant Heating Mat Home Heating Mat Floor Heating Mat Floor Heat Mats

Benefits

There are various types of heating including natural or propane gas and oil, but electric heat, though not always the most efficient

cost-wise (depending on your electricity rates), is probably the most common - mainly because it is readily available in most areas.

Compared to other heating systems, the investment costs for electric underfloor heating are extremely low.

No need for maintenance contracts once the system is installed.

Convenience -- Easy to fix by adhering to the floor and design to install at the site.

All-in-one -- Complete All-in-one with the mat (fiber-glass mesh) and cable to facilitate convenience in the plastering finish.

Flexibility -- possible to install flexibly in any shape at any place.

Easy Installation -- When the mat is unfolded, the cable is attached at certain& intervals and it can be automatically installed.

Separate control for each area. Each area or room can be activated separately.

Installation Guidance

Application Fields

ANLT electric underfloor heating system provides a warm, comfortable and luxurious home environment. For use in every room such as the bathroom, kitchen, living room, utility room, basement, den, or bedroom. And for use in commercial buildings and spaces such as offices, storehouse, markets, classrooms, kindergarten, hotels, hospitals, and in live-stocks and greenhouses, etc.

 Programmable Room Thermostat

ANLT07H - Programmable Touch Screen Thermostat

Power Supply: 85-250VAC

Display resolution: 0.1℃

Setting Unit: 0.5℃/step

Internal sensor measurement range: 0 - 40℃.

Setting range: 5 - 35℃ (default: 25℃)

Inside sensor: NTC B=3380 10k

@25degrees Celsius

Max. switch power: 3A/16A/30A

External sensor measurement range: 0 - 99℃.

Setting range: 5 - 95℃ (default: 50℃)

Extra sensor: NTC B=3380 10k @25 degrees Celsius, length=3 meters

Display type: LCD

Display area: 60 x 45 mm

ANLTE52 - Programmable Digital LCD Display Thermostat

Applicable for hot water radiant and electric heating system.

Voltage: 220±10%VAC, 50/60Hz
Room setting Range: 1℃~50℃ (can adjust to 15℃~90℃)

External limitation: 20℃~90℃ (factory setting 65℃)

Sensor type: NTC

Color: white ivory

Mounting: mounts directly onto wall or wall-box

Relative humidity: <85% (23℃)

Size of display: 58 mm X 35mm (H/W)

ANLT8600 - Programmable Floor Heating Room Thermostat

Power Supply: 100-240VAC 50/60Hz
Power consumption: <1.5w
Setting Time + Black light + Large LCD screen Accuracy: ±1℃
Timing error: <1%
Temperature re-range: 5 - 35℃
Rubber-thermoplastic NTC Sensor Housing material:self-extinguishing PC

ANLT71.36 - Knob / Manual Thermostat

Voltage: 220AVC+/-15% 50/60Hz
Power consumption: 3.5A
Re-range:5-30 Celsius
Maximum load:16A 3000W
Double control, LED indication working
Setting range: 10 ~55℃
Ambient temperature: -5~55℃
Protective housing: IP20

ANLTC70 - Temperature Controller

Power supply: 230 V 50 Hz
Power consumption: 5 W
Adjusting range: 5°C ~ 40°C

Differential per. temp. : 0.5°C
Operating temp.: - 5°C ~ 50°C

Degree of protection: IP20
Material: self-extinguishing PC Floor sensor: NTC sensor 3 m
