Home > Products > Refrigeration Fittings > Compressor

R22 3.5HP 50HZ Q2.2A Dongwei Air conditioning compressor

FOB Price:

US 175-650 / Piece

Min.Order Quantity:

1 Piece/Pieces

Supply Ability:

1000 Piece/Pieces per Month

Port:

Shanghai

Place of Origin:

Jiangsu, China (Mainland)

Payment Terms:

L/C,D/A,T/T

Brand:

Cooltech Dongwei Leek

Products Model:

Products Details
Company Profile

Quick Details

Brand Name: Cooltech Dongwei Leek

Model Number: --

Place of Origin: Jiangsu, China (Mainland)

Packaging & Delivery

Packaging Details: Pallet carto
Delivery Detail: 45 days after receipt of advance

Specifications

R22 3.5HP 50HZ Q2.2A Dongwei Air conditioning compressor
American Tecumseh technology
The Lowest price
World-class equip

R22 3.5HP 50HZ Q2.2A Dongwei Air conditioning compressor

Main features

DONGWEI/TAIKANG series compressor is available for R22/R404A ,being suitable mainly for air condition,commercial refrigeration machine and other medium and large refrigeration machine.

The structure is adopted hermetic crank-connecting rod,double bearing and reciprocating piston,This series compressor is characterized by high efficiency,high reliance ,low vibration level and low sound level.

For air condition,this series is available in 1 to 15 HP application ranges .For commercial refrigeration,this series is available in 2 to 7 HP application ranges.And customers could select the brass connecting and thread connecting with their demands and choose the parallel connecting compressors in some models.

Model		Nominal Power	Nominal Capacity	Displacemert	Oil Charge	Weight	Power
Model		H.P		cm³/rev	cm³	Kg
Q24.1F18.4G-2.0	Q0.75	1	3600	27	1200	26	1PH220V/50HZ
	Q1.1	1.5	4100	33.5	1200	26
	Q1.8	2	5300	41.4	1200	27
	Q2.0	2.5	6300	49.8	1200	27
	Q2.2E	3	8000	58.4	1200	28
	Q1.5S	1.5	4100	33.5	1200	26	3PH380V 50HZ
	Q1.8S	2	5300	41.1	1200	27
	Q2.0S	2.5	6300	49.8	1200	27
	Q2.2SE	3	8000	58.4	1200	28
Q24.7F17.4G-2.2SA	Q2.2A	3.5	8400	61.9	1600	38	1PH220V/50HZ
	Q3.2	4	11000	79.6	1600	39
	Q4.5A	4.5	13000	90.4	1600	39
	Q2.2SA	3.5	8400	61.9	1600	37	3PH380V 50HZ
	Q3.2S	4	11300	79.6	1600	37
	Q4.5SA	4.5	13000	90.4	1600	38
Q34.5F25.9G-5.0S	Q5.0SA	5	14900	113.2	1980	48
	Q5.0S	6	16600	125.2	1980	48
	Q5.5S	7	18500	134	1980	48
Q45.6F24.0G-8.6S	Q8.6S	10	29800	236	4500	80
	Q10.8S	12	33400	250	4500	75
	Q12.9S	15	44700	340	4500	78

Model		Refrigeration Capacity at 50HZ Rated @54.4°C CondTemp.(W)					Run Capacitor
Model		-15	-10	0	7.2	15	F/450VAC
Q24.1F18.4G-2.0	Q0.75	1351	1750	2735	3600	4679	25
	Q1.1	1539	1993	3115	4100	5330	30
	Q1.8	1807	2275	3862	5300	7230	35
	Q2.0	2105	2812	4654	6300	9820	40
	Q2.2E	2714	3630	5862	8000	10210	40
	Q1.5S	1539	1993	3115	4100	5330
	Q1.8S	1807	2275	3862	5300	7230
	Q2.0S	2105	2812	4654	6300	8470
	Q2.2SE	2714	3630	5862	8000	10210
Q24.7F17.4G-2.2SA	Q2.2A	2795	3750	6270	8400	11366	40
	Q3.2	3120	4350	7725	1100	13476	50
	Q4.5A	3916	5246	9115	13000	18377	60
	Q2.2SA	2795	3750	6270	8400	11360
	Q3.2S	3130	4388	7870	11300	15980
	Q4.5SA	3916	5246	9115	13000	18377
Q34.5F25.9G-5.0S	Q5.0SA	4470	6130	105900	14900	20660
	Q5.0S	5157	6967	11860	16600	23360
	Q5.5S	5670	7546	12700	17800	25048
Q45.6F24.0G-8.6S	Q8.6S	8946	12292	21228	29800	41400
	Q10.8S	10020	13768	23775	33400	46368
	Q12.9S	13419	18438	31842	44700	62100

Q2.2E,Q2.2A,Q3.2and Q4.5A must use START CAPACTOR and START RELAY,Q0.75,Q1.1,Q1.8,and Q2.0 should use START CAPACITOR and START RELAY when necessary.

Norminal Capacity under 60HZ is 120%compare with 50HZ ,3PH 460V.

Product

warehouse

The figure using

Transport

We are Dongwei Group subsidiary.
We are a professional supplier in China, specialized in manufacturing and exporting the refrigeration & A/C equipment and accessories.

Our major products include hermetic compressor (both used for air-condition and commercial refrigeration), water-cold condenser, fan-cold condenser, evaporator, air-cooler, fan-cold condensing unit, water-cold condensing unit, refrigerant, freezer tool and A/C part, etc.

Our product and service has been sold to more than 30 countries and areas, including China, the USA, Italy, Turkey, Russia, South Korea, Japan, Hong Kong, Taiwan, Mexico, Venezuela, Brazil, Paraguay, Chile, Argentina, Thailand, Laos, Bangladesh, South Africa etc. Meanwhile, we can design and manufacture the product according to our clients' requests.

We honestly welcome new friends to visit us for communicating and cooperating with us. We hope we can establish good and long-term cooperation relations with new and old clients, hand in hand. We will move towards and create a splendid future jointly!
