AluminumFrame panel Air filter / mesh air filter

FOB Price:

US 5.5-45.5 / Set

Min.Order Quantity:

1000 Set/Sets

Supply Ability:

10000 Set/Sets per Week

Port:

Qingdao

Place of Origin:

Shandong, China (Mainland)

Payment Terms:

L/C,D/A,D/P,T/T,Western Union,MoneyGram

Brand:

AOBO

Products Model:

AB-117

Products Details
Company Profile

Quick Details

Brand Name: AOBO

Model Number: AB-117

Place of Origin: Shandong, China (Mainland)

Packaging & Delivery

Packaging Details: Carton Or packing according to the requirements
Delivery Detail: no more than15 working days after receiving 30% deposit

Specifications

AluminumFrame panel Air filter

mesh air filter

Features

A) High acid and alkali resistance

B) Washable

C) Low initial resistance

D) Firm structure

E)High dust holding capacity and long service life

F)Lightweight and easy to install

·Frame:aluminum alloy frame.

·Media:eAluminum or stainless steel net,asy to install and maintain, High absorb capacity ,nice performance

,low operation Cost,low resistance,washable-reusable aluminum net,long life span.

·Efficiency:(EN779:2002 filter class)G3,G4,F5

(ASHRAE 52.2:2007 filter class)MERV7,MERV8,MERV9.

·Recommended final pressure drop:250Pa.

·Temperature:250°C

·Fire rating:DIN 53438 class F1

Applications

Building air conditioning primary filtration system

The primary filter of industrial-grade ventilation systems

Widely used in industry,M-NET is the most economical ventilation and direct ways

Widely used in acid,alkali and high humidity environment

Common specifications

Model	Dimensions	Face Velocity (m/s)	Rated Air Flow(m3/h)	Initial Pressure Drop
SMW-20102	49223848	2.5	1050	15
SMW-20162	49239046	2.5	1720	15
SMW-20202	49249246	2.5	2170	15
SMW-24242	59459446	2.5	3170	15
SMW-25162	61939046	2.5	2170	15
SMW-25202	61949246	2.5	2740	15

1. If you meet specifications, structural changes, the company provides the newest data shall prevail

2.We accept the orders of non-standard specifications Washable

Samples and product catalogue are available!

Welcome your RFQ!
