China Machine Made Electric Motor Winding Wire Gauge Chart

FOB Price:

US 2.4-3.5 / Kilogram

Min.Order Quantity:

500 Kilogram/Kilograms

Supply Ability:

1000 Ton/Tons per Month

Port:

Shanghai/Qingdao

Place of Origin:

Shaanxi, China (Mainland)

Payment Terms:

L/C,D/A,T/T,Western Union,MoneyGram

Brand:

Galaxy

Products Model:

Products Details
Company Profile

Quick Details

Brand Name: Galaxy

Model Number: --

Place of Origin: Shaanxi, China (Mainland)

Packaging & Delivery

Packaging Details: Packaging Details: different plastic spools according to wire size,cartons with pallet or wooden case as customer's requirements. Delivery Detail:7-10 Days
Delivery Detail: --

Specifications

China Machine Made Electric Motor Winding Wire Gauge Chart

Galaxy mainly supply:

Enameled Copper Wire,Enameled Aluminum Wire,ECCA Wire,Litz Wire,Enameled Rectangular/square Wire

Advantages: as the most traditional type of enameled wire, the application field is wide, soldering convenient, performance stable.

Specifications :

Conductor:copper, aluminum,copper clad aluminum
Diameter: 0.02-4.50mm round enameled aluminum wire
Standard: IEC, NEMA, GB,JIS
Thermal Class: 130/155/180/200/220 centigrade

Enamelled types : UEW,PEW,EIW,EI/AIW,AIW
Certification:UL Approved, iso9001, iso14001,RoHS,REACH

Product details:

Enameled Type	Polyester	Modified Polyester	polyester-imide	Polyamide-imide	polyester-imide /Polyamide-imide
Insulation Type	PEW/130	PEW(G)/155	EIW/180	EI/AIW/200	EIW(EI/AIW)220
Thermal class	130, CLASS B	155, CLASS F	180, CLASS H	200, CLASS C	220, CLASS N
Conductor	Al	Al	Al	Al	Al
Size(mm) supply	0.02-4.5	0.02-4.5	0.02-4.5	0.02-4.5	0.02-4.5
Enamel thickness	Grade(1,2,3)	Grade(1,2,3)	Grade(1,2,3)	Grade(1,2,3)	Grade(1,2,3)

Product Feartures:
High breakdown voltage;good adhesion;Tin sodering;few pinhole;Sustained and stable quality

Main applications:

all kinds of household electric motors,vacum cleaner motor,electric motor;

all kinds of fan motor;

all kinds of high frequency electric appliance;

all kinds of transformer,inductors,rectifiers

Certification:

Workshop:

Xi'an Galaxy Imp & Exp Co., Ltd is a professional supplier, which is engaged in exporting all kinds of enameled copper wires,enameled aluminum wires,enameled copper clad aluminum wires,CCA/CCS/CCAM wires,electric wires and cables , heating cables and mats,power cables,welding cables, solar cables, communication cables and optical fiber wires, We are located in Xi'an city Shaanxi province. In recent years, Among our clients from Northern Europe,Southeast Asia,Africa,Western Europe and so on. we enjoy a good reputation through several year's effort and experience. In addition, our products can meet GB, IEC, UL,BS,AS,ASTM standards. Now our foreign trade department is a strong cohesive force team with professional skills, we are always available to discuss your requirements and ensure full customers' satisfaction. We also welcome OEM and ODM orders. Whether selecting a current product from our catalog or seeking engineering assistance for your application, you can talk to us about your sourcing requirements, we will try our best to give you a perfect solution at first time. Your satisfaction is our motivation . we warmly welcome your contacting.
