Class 130 155 180 200 220 IEC standard enameled cca copper clad aluminum wire enamelled cca wire for induction cooker

enameled copper clad aluminum wire

enamelled copper clad aluminum wire  is a new electromagnetic wire taking copper clad aluminum as inner conductor material, with characteristics between copper and aluminum. It combines excellent conductivity of copper and light weight of aluminum.

Standard of  enameled copper clad aluminum wire

          Reference to SJ/T11223-2000 Copper Clad Aluminum Wire and GB/T6109.1 ~ 11-2008 Enameled Round Winding Wire

Advantages of enameled copper clad aluminum wire

1. DC resistivity: The DC resistivity of CCA wire is approximately 1.45 times that of copper wire; with the same resistance, CCA wire is about 1/2 heavy of copper wire.

2. Good solderability: CCA wire is clad with a layer of concentric copper, so it has the same solderability as copper wire and doesn’t need special treatment as aluminum wire;

3. Light weight: The density of CCA wire is 1/3 of copper wire of the same diameter; very effective to reduce the weight of cables and coils.

Scope of Supply of enameled copper clad aluminum wire

        0.15-4.60 mm

Models of supplies of  enameled copper clad aluminum wire

       QA (N), QZ (N), QZY, and Q (ZY / XY)

Product Types of  enameled copper clad aluminum wire

Polyester Enameled CCA round wire(PEW);

Polyurethane Enameled CCA round wire(UEW);

Polyesterimide enameled CCA round wire(EIW);

Polyesterimide over-coated with polyamide-imide enameled CCA round wire(EIW/AIW).

Applications of  enameled copper clad aluminum wire

1. High-frequency transformers, general transformers;
2. Induction coils, magnetic coils;
3. Electromotors including household electromotors, a variety of micro-motors, compressors, and other electromotors with high environment requirements;

4. Special electromagnetic wire for audio coils and CD drivers;
5. Electromagnetic wire for monitor deflection coils;
6. Various types of magnetic coils and induction coils;

  Our Services

1)- Factory Direct and on-time shipment.

2) -ELANTAS insulation paint available.  enameled copper wire price

3) -Large size safe package up to PT-270.

4) -Customized sizes,logos and packing are accepted!

5) -Goods are sold with rerun or refund guarantee due to quality issue!

6) -Exported to over 50 countries, more than 200 overseas customers.
