Home > Products > Refrigeration Equipment > Ice Machine

CE/ISO approved 20Ton daily output Large industrial flake ice machine for ice plant

CE/ISO approved 20Ton daily output Large industrial flake ice machine for ice plant

FOB Price:

US 500-13000 / Set

Min.Order Quantity:

1 Set/Sets

Supply Ability:

1000 Set/Sets per Month

Port:

Shanghai Port /Tianjin Port

Place of Origin:

Hebei, China (Mainland)

Payment Terms:

L/C,D/A,D/P,T/T,Western Union,Payment terms for Flake ice machine 20tons/day can be discussed

Brand:

JSWW

Products Model:

JW-F20

Products Details
Company Profile

Quick Details

Brand Name: JSWW

Model Number: JW-F20

Place of Origin: Hebei, China (Mainland)

Packaging & Delivery

Packaging Details: Packaging way:Carton&wooden frame for CE/ISO approved 20Ton daily output Large industrial flake ice machine for ice plant
Delivery Detail: Within 25Days

Specifications

CE/ISO approved 20Ton daily output Large industrial flake ice machine for ice plant

Characteristics

JW small commercial flake ice machines widely used in superparket chains, hotels, seafood market, food processing and vegetable preservation industries, etc.
The parts of small commercial flake ice machine refrigerating unit are all from America, Germany, Japanand other countries that have leading refrigeration technology.
The whole system controlled by automatic microcomputer, The ice machine can start and stop automatically to make the evaporator mechanical operation system and water suppling circulation system coordination matched and work safety & efficiently under the function os PLC programmable controller. Thewhole system is protected by the alarm of water shortage, ice full, high and low pressure abnormal, power phase inverse and conpressor overload etc, with tthe computer intelligence control. When there is a failure, the PLC with stop the unit automatically and the corresponding alarming indicator lights up. And when settled, PlC controler will soon start the machine after receiving the information, thus full automatic control realized.

Product Description

Fish farm 20Tons flake ice machine description:

1.Flake ice production range:

300 kg - 30 tons / day

2.Evaporator:

Made with a sandwich stainless steel (or carbon) vertical cylinder, the refrigerant evaporated in the sandwich, water spraying in the cylinder wall and then rapid freezing, by continuously rotating stainless steel skates squeeze the ice, excess water back to the tank through the baffle, recycling once more.
3.Ice features:

Ice shape: ice irregular scaly.

Thickness 1.5-2.5MM.

No sharp edges and corners,contact area larger, cooling faster.
4.Multi spiral cutter:

Reducing equipment energy consumption, no friction with cylinder wall in avoild of refrigerant leaks.
Steel with chrome plating,or quality 304, / 316 stainless steel, ensure good heat transfer efficiency.
5.PLC control, less failure, maintenance is simple and convenient.

Product Overviews

Technical parameters

Parameters of CE/ISO approved 20Ton daily output Large industrial flake ice machine for ice plant

Model	Maximun Capacity(kg)	Ice shape	Storage Capacity(kg)	Dimension (WDH)mm	Power	Refrigerant	Condenser
JW-F200	200		150	730760600	220V1100W	R22
JW-F500	500	Flake ice	280	7608301750	220V1500W	R22/R404a	Air/Water
JW-F1000	1000		400	131010601700	380V3900W	R22/R404a
JW-F2000	2000		1000	155014002100	380V6700W	R22/R404a
JW-F2500	2500		1000	155014002200	380V8500W	R22/R404a
JW-F3000	3000		1200	165014602800	380V9800W	R22/R404a
JW-F4000	4000		2000	175015501250	380V18.32kw	R22/R404a
JW-F5000	5000		3000	175015501600	380V23.122kw	R22/R404a
JW-F6000	6000		3000	175015501600	380V26.15kw	R22/R404a
JW-F8000	8000		4000	253018301680	380V31.5kw	R22/R404a
JW-F10	10000		5000	253018301820	380V45.5kw	R22/R404a
JW-F15	15000		7500	310020901865	380V64kw	R22/R404a
JW-F20	20000		10000	369520902050	380V75.8kw	R22/R404a
JW-F25	25000		12500	369520902265	380V97.8kw	R22/R404a
JW-F30	30000		15000	388021202400	380V115.7kw	R22/R404a

Certifications
