ZVF330-M Series Frequency Inverter

Main Technic Data

Input

Rated voltage& Frequency

Single /Three phase 220VAC, Three phase 380V.50Hz/60Hz

Allowable Voltage range

Voltage fluctuate range:-20%~+20%
Voltage unbalance rate:<3%;Frequency fluctuation:≤5%

Output

Rated voltage

three phase 0~  input AC voltage

Frequency

0.00~600.00Hz

Overload capacity

Type G:150% 1minute,180% 1 second,200% transient protection
Type P:120% 1minute,150% 1 second,180% transient protection

Control Function

Modulation mode

Optimal space voltage vector PWM modulation

Control mode

Sensorless  vector control (SVC), V/F control . Torque control

Frequency accuracy


Digital setting::Max. Frequency×±0.01%
Analog setting:Max. Frequency×±0.2%

Frequency resolution

Digital setting :0.01HZ;
Analog setting :Max. Frequency x0.1%.

Starting frequency

0.00~10.00Hz

Torque lift

Automatic torque lift: To lift the torque automatically according to the output current.
Manual torque lift, Range: 0.1_30.0%

Slip compensation

Setting range:0~150%,The inverter output frequency can be auto-regulated within this range according to the motor load, so as to reduce the speed variation of the motor due to load fluctuation.

Acceleration/deceleration
time

Minutes/Seconds can be selected as time unit .0.1~3600 can be set in sequence .

Carrier frequency

1.0~15.0KHz

Jog function

Jog frequency range:0.01~600.00Hz,
Jog acceleration /deceleration time 0.1~3600.0 can be set.

V/F curve

1: linear curve; 2: quadratic;3: user defined V/F curve

Automatic energy-saving operation

Auto optimize V/F curve according to the load changes to realize the energy saving operation.

Auto voltage regulation(AVR)

When the network voltage changes, it can regulate PWM output automatically to maintain constant voltage.

Built-in PID

This can form a convenient closed-loop control system (CLCS)and is applicable to pressure control, flow control and other process control  .

Operation Function

Operating command

Operation panel control ,external terminal control and COM control

Frequency setting

Keypad potentiometer setting , operation panel up /down setting,. external terminal UP/DOWN setting, analog voltage signal or external potentiometer setting , analog current signal setting .terminal combination setting ,485 COM setting and so on.

Input Signal

Forward/Reverse signal\multi-speed signal \fault signal \
reset signal etc.

Output signal

Programmable relay\open collector output \Fault  signal output.

Output signal

Programmable relay\open collector output \Fault  signal output.

Multi-function analog and digital output terminal

This can realize the output of frequency current and other physical quantity by output 0-10V or 0-20mA DC signal and 0-10KHz digital signal output.

Braking Function

Dynamic braking

With an external braking resistor, the maximum braking torque may reach 100%.

DC Braking

This can be selected when the motor starts or stops with the action frequency of 0-20Hz,action current level of 0-100% and actuation time of 0-30sec., which can be set in sequence.

Other Function

Skip frequency\Jog function\Counter \Rotation speed tracking\Momentary power loss restart \Frequency upper/lower limiting\Acceleration/ Deceleration mode can be adjusted \Frequency meter and Voltmeter output \Multi-speed/ program running \Two wire mode/ three wire mode control \Wobble frequency control\Multi-function input terminal selection \Fault auto reset\RS485 serial communication .

Protection Function

Input phase loss protection\Over current protection \Overload protection\Over voltage protection \Under voltage protection\Over heat protection ect.
