Brand Name: SOLOON CONTROLS
Model Number: S6061SF-2.5DFS/24V
Place of Origin: BEIJING
S6061SF-2.5 series fire smoke damper actuator
Summary:
Specially designed for small and medium air damper and control unit used in air volume system. Because of its small size and flexible control, it usually used in such places where the space is limited.
Features:
l Shaft size up to 12* 12mm
l On/off type can be controlled by manual
l Two fixed auxiliary switches available
l Using fixed, compact and anti-impact steel shell
l With IP54 standard
l Used in different mounting size mandril accessories that with fireproofing and mounting easily.
Technical datasheet:
|
Unit |
S6061SF- 2.5DF/24V |
S6061SF- 2.5DF/230V |
S6061SF- 2.5AF/24V |
|||
|
Torque |
Nm |
2.5Nm |
||||
|
Damper area |
m2 |
0.5m2 |
||||
|
Running time |
sec |
Motor 60~70S；spring return 25~30S |
||||
|
Power supply |
V |
24VAC/DC 50/60Hz；230VAC 50/60Hz |
||||
|
Operating Power Consumption |
W |
2.5W |
||||
|
At end stops Power Consumption |
W |
1.6W |
||||
|
Wire size |
VA |
10VA |
7VA |
|||
|
Weight |
Kg |
1.2 |
||||
|
Control signal |
On/off |
0~10V |
||||
|
Rotation angle |
0~90°（Max 93º） |
|||||
|
Auxiliary switch rating |
3（1.5）Amp 250V |
|||||
|
Life cycle |
70000 |
|||||
|
Noise |
50dB(A) and 65dB(A) |
|||||
|
Electric level |
Ⅲ |
Ⅱ |
||||
|
IP protection |
IP54 |
|||||
|
Temperature |
-20~+50℃ |
|||||
|
Humidity |
5~95%RH |
|||||
|
Storage temperature |
-40~+70℃ |
|||||
|
Certificate |
CE |
|||||
|
72℃ thermal sensor |
S6061SF-2.5DF(S)/24V（yes） |
S6061SF-2.5DF(S)/220V（yes） |
||||
|
S6061SF-2.5DF/24V （no） |
S6061SF-2.5DF/220V （no） |
|||||
Note: there is no manual function for S6061SF-2.5AF/24V
Special suggestion: Manual operation instruction
Insert the handle into the hex hole, turn around the handle by clockwise (or anti-clockwise) according to the diagram of the product’s label. The output shaft will follow and turn by clockwise at the same time. When the output shaft moves to the required position, turn the handle by anti-clockwise with 90 degrees, and then can lock the actuator at current position. If want to unlock the actuator, turn the handle 360 degrees by clockwise (or anti-clockwise) according to the product’s label, when listening to the sound of “pa”, the actuator has already unlocked.
