Home > Products > Air Conditioner > Residential Air-conditioner

30000 btu 2 5 ton general split wall mounted air conditioner

30000 btu 2 5 ton general split wall mounted air conditioner

FOB Price:

US 275-399 / Set

Min.Order Quantity:

100 Set/Sets

Supply Ability:

500000 Set/Sets per Year

Port:

Ningbo

Place of Origin:

Zhejiang, China (Mainland)

Payment Terms:

L/C,D/P,T/T

Brand:

AKL or OEM

Products Model:

KF-90GW/B1 KF-100GW/B1

Products Details
Company Profile

Quick Details

Brand Name: AKL or OEM

Model Number: KF-90GW/B1 KF-100GW/B1

Place of Origin: Zhejiang, China (Mainland)

Packaging & Delivery

Packaging Details: 1pc/carton box 30000 btu 2.5 ton general split wall mounted air conditioner
Delivery Detail: Shipped in 25 days after payment

Specifications

30000 btu 2.5 ton general split wall mounted air conditioner

1:Use the known brand rotary type compressor;

2:High Efficient Internal Thread Copper pipe;

3:LED digital display, Fault Self-Diagnose Code Showing;

4:Self-diagnose capability, error code showing;

5:Intelligent Defrost,Independent Dehumidification,Sleep Mode,Quiet Operation;

6:Low Voltage Startup,Auto—protection,Auto Restart;

7:Optional Refrigerant:R410A & R22 ;

8:Optional Voltage:220V/50Hz & 220V/60Hz;

9:With CE,RoHS ,ISO9001, ISO14001 standard;

10:Sales Area:Mid East,Africa ,South America,Europe,Asia,Central America,Oceania;

B1-Series
Model	9000BTU	12000BTU	18000BTU	24000BTU	30000BTU	36000BTU
0.75Ton	1Ton	1.5Ton	2Ton	2.5Ton	3Ton
Factory Model	Cooling	KF-25GW/B1	KF-35GW/B1	KF-50GW/B1	KF-70GW/B1	KF-90GW/B1	KF-100GW/B1
Cooling&Heating	KFR-25GW/B1	KFR-35GW/B1	KFR-50GW/B1	KFR-70GW/B1	KFR-90GW/B1	KFR-100GW/B1
Optional Power Supply	Ph-V-Hz	1.220V-240V/50Hz 0r 1.208V-230V/60Hz
Rated Cooling Capacity	w	2500	3500	5000	7000	9000	10000
Rated Cooling input	w	890	1270	1850	2500	3250	3650
Rated Cooling Current	A	4	5.8	8.4	11.4	14.7	16.6
EER	Btu/w.h,w/w	10/2.8	9.5/2.75	9.7/2.7	9.6/2.8	9.2/2.77	9.9/2.74
Rated Heating Capacity	w	2550	3600	5050	7100	9050	10500
Rated Heating input	w	880	1280	1800	2450	3230	3820
Rated Heating current	A	4	5.8	8.2	11	14.7	17.4
COP	(w/w)	2.9	2.8	2.8	2.9	2.8	2.75
Operation temp	°C	18-30	18-30	18-30	18-30	18-30	18-30
Ambient temp	°C	-7-53	-7-53	-7-53	-7-53	-7-53	-7-53
Indoor / Outdoor unit Noise	dB(A)	36/50	38/52	39/53	42/61	45/63	45/65
Indoor / Outdoor unit Weight	Kg	9/28,	10.5/35	14/49	17/55	25/78	25/92
Outdoor Unit Packing Dimension	mm	720310550	790340600	860340600	910390710	1050410895	1050410895
Indoor unit Packing Dimension	mm	805×305×255	855×305×255	985×365×298	1103×400×300	1103×400×300	1317×422×338
Note:All the data in the brochure is only for reference,designs and specifications might be changed without prior notice for;

B1-Series

Model

9000BTU

12000BTU

18000BTU

24000BTU

30000BTU

36000BTU

0.75Ton

1Ton

1.5Ton

2Ton

2.5Ton

3Ton

Factory Model

Cooling

KF-25GW/B1

KF-35GW/B1

KF-50GW/B1

KF-70GW/B1

KF-90GW/B1

KF-100GW/B1

Cooling&Heating

KFR-25GW/B1

KFR-35GW/B1

KFR-50GW/B1

KFR-70GW/B1

KFR-90GW/B1

KFR-100GW/B1

Optional Power Supply

Ph-V-Hz

1.220V-240V/50Hz 0r 1.208V-230V/60Hz

Rated Cooling Capacity

2500

3500

5000

7000

9000

10000

Rated Cooling input

890

1270

1850

2500

3250

3650

Rated Cooling Current

5.8

8.4

11.4

14.7

16.6

EER

Btu/w.h,w/w

10/2.8

9.5/2.75

9.7/2.7

9.6/2.8

9.2/2.77

9.9/2.74

Rated Heating Capacity

2550

3600

5050

7100

9050

10500

Rated Heating input

880

1280

1800

2450

3230

3820

Rated Heating current

5.8

8.2

14.7

17.4

COP

(w/w)

2.9

2.8

2.9

2.8

2.75

Operation temp

°C

18-30

Ambient temp

°C

-7-53

Indoor / Outdoor unit Noise

dB(A)

36/50

38/52

39/53

42/61

45/63

45/65

Indoor / Outdoor unit Weight

9/28,

10.5/35

14/49

17/55

25/78

25/92

Outdoor Unit Packing Dimension

720*310*550

790*340*600

860*340*600

910*390*710

1050*410*895

Indoor unit Packing Dimension

805×305×255

855×305×255

985×365×298

1103×400×300

1317×422×338

Note:All the data in the brochure is only for reference,designs and specifications might be changed without prior notice for;

AKL Heat Pump Technology Co., Ltd founded in 2002, is a professional manufacturing enterprise that specializes in the development & research, manufacturing and sales of air conditioner and air source heat pump. We are located in the port city, Ningbo which is a household appliance producing base in china.

Our company has the advanced product performance laboratory and perfect inspection equipment for production. The people in charge of technical development and quality management are all the professionals from the industry, so we have strong abilities of technical development and quality management. We have passed the international quality certificates like CCC, CE, SASO, ISO9001, ISO1400, RoHS, etc.

So far, AKL Company has an annual output of air conditioner and air source heat pump about 600,000 sets. We have rich experience in producing OEM products. More than 80% of air conditioners and air source heat pumps are sold to more than 50 countries and regions, such as Europe, Africa, South America, Asia, Taiwan, etc. We have the qualification to self-operate import and export
