CE Certificate Best selling High Efficiency Biomass Thermal Oil Boiler Hot Oil Boiler

CE Certificate Best selling High Efficiency Biomass Thermal Oil Boiler Hot Oil Boiler

FOB Price:

US 10000-30000 / Set

Min.Order Quantity:

1 Set/Sets

Supply Ability:

2000 Set/Sets per Year

Port:

Qingdao/Tianjin/Shanghai, as your request for biomass thermal oil boiler

Place of Origin:

Henan, China (Mainland)

Payment Terms:

L/C,D/A,D/P,T/T,Western Union,MoneyGram,ESCROW

Brand:

YUTONG

Products Model:

YGL/YLL/YLW

Products Details
Company Profile

Quick Details

Brand Name: YUTONG

Model Number: YGL/YLL/YLW

Place of Origin: Henan, China (Mainland)

Packaging & Delivery

Packaging Details: with professional seaworthy packing for biomass thermal oil boiler.
Delivery Detail: Within 20 working days agianst of advance payment

Specifications

Industrial Thermal Oil Heater Biomass Thermal Oil Boiler Hot Oil Boiler

Product Description:

this series boiler is a new type of special boiler with low-pressure ,high-temperature. the heating temperature can reach liquid 340 degree or steam 400 degree.if you craft need to be heated stable and do not allow to use flame directly ,it can reach 150 degree--380 degree and used in a variety of productions situations.

The furnace use general coal ,oil and steam as fuel,and this series boiler takes heat carrier oil as medium and uses the hot oil ciculating pump force the medium to make liquid circulation; then the furnace to be reheated ,so the boiler can get higher working temperature at low pressure ,and make a better usage of heat ,it is a kind of safe boiler with high effciency and low power consuption .

main features:

(1), access to low-pressure high-temperature thermal medium, convenient adjustment, heat evenly, to meet precise process temperature.

(2), liquid circulation heat, no condensation heat loss emissions, high thermal efficiency heating system.

(3), the working medium heat and heat and temperature fluctuation on the volume change in the compensation measures within the system.

(4), circulating heat medium before the strict control of air, water and other low volatile content of the technical measures.

Why choose thermal oil boiler ?

1. The choice between a steam system or a thermal fluid system is governed by the process requirements. The range or process temperature is a deciding factor. If the systems required temperature is above the freezing point of water (32°F) and below approximately 350°F, the choice is usually steam. However, if the required temperature is below 32°F or above 350°F, thermal fluid may be a better solution.

2. Reliability and rugged long life construction ;

3. Guarantee on both the burner and the boiler ;

4. Efficiency, which can be higher than 92% over the operating range ;

5. Investments and maintenance costs reduced ;

6. Optimised heat balance, associates the high output of the boiler with very low thermal losses on the distribution system which means very high overall plant efficiency ;

7. Very short response time, low inertia ;

8. Optimisation of the thermal coefficient of transfer of the boundary layers ;

9. Low pressure of operation normally no more than total system resistance (10 bar max) for high temperature (350°C) ;

10. Well suited for indirect process heating;

Biomass Thermal Oil Boiler Technical parameters

Data	Type	Parameters	YLW- 1900MA	YLW- 2300MA	YLW- 2900MA	YLW- 3500MA	YLW- 4100MA	YLW- 4700MA	YLW- 5900MA	YLW- 7000MA	YLW- 8200MA	YLW- 9400MA	YLW- 12000MA	YLW- 14000MA
Rated power Kw			1900	2300	2900	3500	4100	4700	5900	7000	8200	9400	12000	14000
Heating load×104kcal/h			160	200	250	300	350	400	500	600	700	800	1000	1200
Thermal efficiency%			76	76	76	76	76	76	76	76	76	76	76	76
Design pressure Mpa			1.1	1.1	1.1	1.1	1.1	1.1	1.1	1.1	1.1	1.1	1.1	1.1
Maximum working temperature			320	320	320	320	320	320	320	320	320	320	320	320
Medium circulation load m³/h			160	160	200	200	260	260	300	340	400	520	600	680
Volume of medium in boiler m3			2.8	3	4	4.5	5.1	5.5	7.2	8.3	8.9	9.9	12.3	16
Caliber of master tube DN			150	150	200	200	200	200	250	250	250	300	300	350
Installed capacity kw			75	90	100	100	120	140	175	215	215	270	315	380
Appropriate coal material			Similar soft coal
Coal consumption kg/h			360	450	565	678	790	904	1130	1356	1582	1808	2260	2710

More pictures of biomass thermal oil boiler for your reference

Henan Sitong boiler Co., Ltd. is the national fixed-point production grade A boiler manufacture enterprise. Sitong boiler industrial park adjacent to national highway No.311 and Zhou-Shang expressway, the traffic is convenient, radiation far-reaching. Our company has perfect quality assurance system and advanced production technology, Rigorous scientific management mode and excellent service before-selling, sale and after-selling, Deep farce management concepts and the elegance of the enterprise culture. In the Trade Union, Our Company may be said that: brilliant achievements and well-established. It is also "Sitong boiler finds its way into every family, safety warm him, you and I.

Our major products are coal, oil, gas, steam (hot) water boiler, Electric heating steam (hot) water boiler, Environment and Energy-saving half gas boiler steam (hot) water boiler, Organic heat carrier furnace, Wastes incinerator, High, medium-temperature hot air stove and other 18 series of 100 specifications. Our company has strong development capacity, professional development engineer adopts CAD computer design, clay modelling and rapid prototyping technology, use the optical 3D scanner to engage in data acquisition engineering, and apply to auxiliary product appearance design, to complete test analysis and detection equipment and tools. Thus we make you enjoy the frontier technology of infinite scene from design and manufacturing of each procedure.

Our Company adhere to the science and technology as the guide, human as the support, quality as assurance and service continuously advance. and follow the management idea of "While a boiler leaves our factory , we make a friend, build a demonstration project and develop a piece of the market", 24 hours of experts substation telephone and computer network service, so as to provide sincerely help at any moment. We constantly win more market share and the trust of customers, which lay the foundation for the internationalization of "Sitong boiler".

Qualification massiness, enterprises culture full-bodied, technology-first, "Sitong boiler" walk the development of "Industrialization, Scalization and Branding", targeting technology commanding heights, building a "Yutong" brand, create the China boiler industry brilliancy hand in hand with the domestic colleague.
