Home > Products > Heating > Boiler

VARIOUS Series Hot Selling 80 Heating Efficiency Best Thermo Oil Boiler

FOB Price:

US 9999-49900 / Unit

Min.Order Quantity:

1 Unit/Units

Supply Ability:

60 Unit/Units per Month

Port:

Shanghai/Qingdao/Tianjin or other

Place of Origin:

Henan, China (Mainland)

Payment Terms:

L/C,T/T,D/A

Brand:

SITONG

Products Model:

YGL

Products Details
Company Profile

Quick Details

Brand Name: SITONG

Model Number: YGL

Place of Origin: Henan, China (Mainland)

Packaging & Delivery

Packaging Details: Plywood case professional packaging transportation
Delivery Detail: within 15working days

Specifications

Thermal Oil Heater , coal or wood or biomass fired thermal oil heater , coa coal fired chain grate stoker boiler l fired chain grate stoker boiler ,Boiler for wood industry

This series boiler is a new type of special boiler with low-pressure ,high-temperature,The heating temperature can reach liquid 340°c or steam 400°c, if you craft need to be heated stable and do not allow to use flame directly,it can reach 150°c--380°c and used in a variety of production situations,The furnace use generally coal,oil and gas as fuel,and this series boiler takes heat carrier oil as medium and uses the hot oil circulating pump force the medium to make Liquid circulation;then the thermal energy will transmitted to the devices and back to the furnace to be reheated.so the devices and back to the furnace at low pressyre,and make liquid circulation; then the thermal energy will be transmitted to the devices and back to the furnace to be reheated,So the boiler can get high working temperature at low pressure,and make a better usage of heat,it is a kind of safe boiler with high efficiency and low power consumption

Uses:

1,Chemical industry-polymerization industry,oil industry,reaction tank,distillation,enrichment;

2 ,Plastic industry-plastic and squeeze to finalize the design;

3 Textile industry- resin stenters,dyeing machine and the dry room,high temperature machine,roller;

4 Rubber industry-cooking,dry,vegetable oil refining

6 Wood industry-heating to finalize the design of chipboard,sandwich plate,wamu board,fiber;

7 Paper industry-multi-layer cardboard of packed carton box,dying and desiccation

8 Others-heating of metal electroplating slot,coating condensation,drying,distillation of pharmaceutical industry,reduction,concentration,dehydration,air conditioning industry,etc

Technical Parameters of YLL

Model		YLL-1400MA	YLL-1800MA	YLL-2400MA	YLW-1400MA	YLW-1800MA	YLW-2400MA	YLW-3500MA	YLW-4600MA
Rated Power		1400	1800	2400	1400	1800	400	3500	4600
Heating efficiency(%)		75	75	75	75	75	78	78	78
Design pressure(MPa)		0.9	0.9	0.9	0.9	0.9	0.9	0.9	0.9
working pressure(MPa)		0.6	0.6	0.6	0.6	0.6	0.6	0.6	0.6
working temperature (ºC)		320	320	320	320	320	320	320	320
Furnace oil capacity		1.26	1.75	2.45	0.93	1.8	2.63	3.8	4.6
Circulation oil capacity (m3)		80	100	150	80	115	155.7	188	241
Connection diameter(mm)		125	150	150	125	150	150	200	200
Dimension	Length(mm)	4830	5300	5800	6200	6360	6852	7595	7768
	Width(mm)	2500	2620	2650	2300	2320	2500	2925	3300
	Height(mm)	5500	5700	6000	3200	4420	5563	5720	6784
weight (T)		15.3	15.3	21	14.7	18.1	27.8	38	43.5

Henan Sitong boiler Co., Ltd. is the national fixed-point production grade A boiler manufacture enterprise. Sitong boiler industrial park adjacent to national highway No.311 and Zhou-Shang expressway, the traffic is convenient, radiation far-reaching. Our company has perfect quality assurance system and advanced production technology, Rigorous scientific management mode and excellent service before-selling, sale and after-selling, Deep farce management concepts and the elegance of the enterprise culture. In the Trade Union, Our Company may be said that: brilliant achievements and well-established. It is also "Sitong boiler finds its way into every family, safety warm him, you and I.

Our major products are coal, oil, gas, steam (hot) water boiler, Electric heating steam (hot) water boiler, Environment and Energy-saving half gas boiler steam (hot) water boiler, Organic heat carrier furnace, Wastes incinerator, High, medium-temperature hot air stove and other 18 series of 100 specifications. Our company has strong development capacity, professional development engineer adopts CAD computer design, clay modelling and rapid prototyping technology, use the optical 3D scanner to engage in data acquisition engineering, and apply to auxiliary product appearance design, to complete test analysis and detection equipment and tools. Thus we make you enjoy the frontier technology of infinite scene from design and manufacturing of each procedure.

Our Company adhere to the science and technology as the guide, human as the support, quality as assurance and service continuously advance. and follow the management idea of "While a boiler leaves our factory , we make a friend, build a demonstration project and develop a piece of the market", 24 hours of experts substation telephone and computer network service, so as to provide sincerely help at any moment. We constantly win more market share and the trust of customers, which lay the foundation for the internationalization of "Sitong boiler".

Qualification massiness, enterprises culture full-bodied, technology-first, "Sitong boiler" walk the development of "Industrialization, Scalization and Branding", targeting technology commanding heights, building a "Yutong" brand, create the China boiler industry brilliancy hand in hand with the domestic colleague.
