BEST QUALITY HOT SALE SITONG Transformer Oil Heater Diesel oil heater

FOB Price:

US 3000-99000 / Set

Min.Order Quantity:

1 Set/Sets

Supply Ability:

1000 Set/Sets per Year

Port:

Qingdao/Shanghai/Tianjin and so on

Place of Origin:

Henan, China (Mainland)

Payment Terms:

L/C,D/A,T/T,D/P

Brand:

Sitong

Products Model:

YGL

Products Details
Company Profile

Quick Details

Brand Name: Sitong

Model Number: YGL

Place of Origin: Henan, China (Mainland)

Packaging & Delivery

Packaging Details: machinery export standard package,auxiliary equipments in plywood,waterproofing packing
Delivery Detail: within 25-30working days

Specifications

Thermal Oil Heater ,Thermal Oil Boiler

This series boiler is a new type of special boiler with low-pressure ,high-temperature,The heating temperature can reach liquid 340°c or steam 400°c, if you craft need to be heated stable and do not allow to use flame directly,it can reach 150°c--380°c and used in a variety of production situations,The furnace use generally coal,oil and gas as fuel,and this series boiler takes heat carrier oil as medium and uses the hot oil circulating pump force the medium to make Liquid circulation;then the thermal energy will transmitted to the devices and back to the furnace to be reheated.so the devices and back to the furnace at low pressyre,and make liquid circulation; then the thermal energy will be transmitted to the devices and back to the furnace to be reheated,So the boiler can get high working temperature at low pressure,and make a better usage of heat,it is a kind of safe boiler with high efficiency and low power consumption

Uses:

1,Chemical industry-polymerization industry,oil industry,reaction tank,distillation,enrichment;

2 ,Plastic industry-plastic and squeeze to finalize the design;

3 Textile industry- resin stenters,dyeing machine and the dry room,high temperature machine,roller;

4 Rubber industry-cooking,dry,vegetable oil refining

6 Wood industry-heating to finalize the design of chipboard,sandwich plate,wamu board,fiber;

7 Paper industry-multi-layer cardboard of packed carton box,dying and desiccation

8 Others-heating of metal electroplating slot,coating condensation,drying,distillation of pharmaceutical industry,reduction,concentration,dehydration,air conditioning industry,etc

Detailed description of thermal oil heater

Main Features:

1, with low voltage, high temperature, safety, high efficiency and energy saving characteristic.

2, having complete operating control and safety monitoring device, can control the working temperature precision.

3, reasonable structure, form a complete set, short instrallation cycle, operation and convenient maintenance, facilitate boiler layout.

4, because electrical heating organic heat carrier furnace adopts advanced explosion-proof structure, can be applied to factory area explosion-proof, explosive-proof grade can reach grade.

Technical Parameters of YGL

Name Parameters Model		YGL -120MA	YGL -230MA	YGL -350MA	YGL -470MA	YGL -700MA	YGL -930MA	YGL -1200MA	YGL -1400MA
Nominal Thermal Rating KW		120	230	350	470	700	930	1200	1400
Thermal Efficiency %>=		65	70	73	73	73	73	73	73
Design Pressure Mpa		0.6	0.6	0.6	0.6	0.6	0.6	0.6	0.6
Maximum Working Temperature °C		320	320	320	320	320	320	320	320
Let Oil of the Furnace m3		0.07	0.22	0.28	0.38	0.55	0.75	0.86	0.95
Oil Cycle Delivery m3/h		12.5	20	40	60	80	100	100	100
Piping Connections Caliber DN		50	80	80	100	100	125	125	125
System Installed Capacity kw		8	10	18	22	25	35	35	35
Overall Dimension mm	Diameter	1215	1500	1650	1700	2030	2160	2160	2200
Overall Dimension mm	Height	2310	2750	2850	3300	3450	3850	4250	5100
Approx. Weight kg		2500	3200	4800	5300	5800	6200	6700	7300

Henan Sitong boiler Co., Ltd. is the national fixed-point production grade A boiler manufacture enterprise. Sitong boiler industrial park adjacent to national highway No.311 and Zhou-Shang expressway, the traffic is convenient, radiation far-reaching. Our company has perfect quality assurance system and advanced production technology, Rigorous scientific management mode and excellent service before-selling, sale and after-selling, Deep farce management concepts and the elegance of the enterprise culture. In the Trade Union, Our Company may be said that: brilliant achievements and well-established. It is also "Sitong boiler finds its way into every family, safety warm him, you and I.

Our major products are coal, oil, gas, steam (hot) water boiler, Electric heating steam (hot) water boiler, Environment and Energy-saving half gas boiler steam (hot) water boiler, Organic heat carrier furnace, Wastes incinerator, High, medium-temperature hot air stove and other 18 series of 100 specifications. Our company has strong development capacity, professional development engineer adopts CAD computer design, clay modelling and rapid prototyping technology, use the optical 3D scanner to engage in data acquisition engineering, and apply to auxiliary product appearance design, to complete test analysis and detection equipment and tools. Thus we make you enjoy the frontier technology of infinite scene from design and manufacturing of each procedure.

Our Company adhere to the science and technology as the guide, human as the support, quality as assurance and service continuously advance. and follow the management idea of "While a boiler leaves our factory , we make a friend, build a demonstration project and develop a piece of the market", 24 hours of experts substation telephone and computer network service, so as to provide sincerely help at any moment. We constantly win more market share and the trust of customers, which lay the foundation for the internationalization of "Sitong boiler".

Qualification massiness, enterprises culture full-bodied, technology-first, "Sitong boiler" walk the development of "Industrialization, Scalization and Branding", targeting technology commanding heights, building a "Yutong" brand, create the China boiler industry brilliancy hand in hand with the domestic colleague.
