Shoe factory used thermal oil boiler best selling for shoe factory

FOB Price:

US 2000-8000 / Set

Min.Order Quantity:

1 Set/Sets

Supply Ability:

350 Set/Sets per Month

Port:

Shanghai Qindao Tianjin

Place of Origin:

Henan, China (Mainland)

Payment Terms:

L/C,T/T

Brand:

Yutong

Products Model:

YY(Q)W

Products Details
Company Profile

Quick Details

Brand Name: Yutong

Model Number: YY(Q)W

Place of Origin: Henan, China (Mainland)

Packaging & Delivery

Packaging Details: Plywood case professional packaging transportation
Delivery Detail: within 15-20 working days

Specifications

Shoe factory used thermal oil boiler best selling for shoe factory

Henan Sitong boiler Co.,ltd is devoted to heat energy field and working to develop efficient,safe,environmental protection,energy-saving heating equipment.Our company applied rich experience and knowledge to the design and development,has the world leading heating technology.Our company develops a full series on heating equipment,including hot water boiler,steam boiler,hot air stove ,organic heat carrier furnace,etc.

Technical parameter

Model	YY(Q)W-120YC	YY(Q)W-230YC	YY(Q)W-350YC	YY(Q)W-470YC	YY(Q)W-700YC	YY(Q)W-930YC	YY(Q)W-1200YC	YY(Q)W-1400YC	YY(Q)W-1800YC	YY(Q)W-2300YC	YY(Q)W-2900YC	YY(Q)W-3500YC	YY(Q)W-4100YC	YY(Q)W-4700YC	YY(Q)W-5800YC
rated power	120	230	350	470	700	930	1200	1400	1800	2300	2900	3500	4100	4700	5800
thermal efficiency	85
Design pressure(Mpa)	0.9
work pressure(Mpa)	0.6
Highest working temperature	320
Furnace capacity( m3 )	0.1	0.2	0.28	0.38	0.55	0.75	1	1.3	1.6	2	2.4	3	3.2	3.7	4.5
Oil circulation( m3 )	12.5	32	40	60	80	100	100	100	160	160	200	200	200	260	300
tubing diameter(mm)	50	65	80	80	100	125	125	125	125	150	150	150	200	200	250
Diameterwidthheight(m)	1.51.1151.4	2.02.51.5	2.51.351.65	2.71.61.9	3.11.651.95	3.51.72.0	3.851.82.16	4.351.92.27	4.82.02.5	5.32.22.75	5.52.43.0	5.82.53.1	6.32.83.3	6.53.03.5	7.03.13.6
reference weight	2	2.9	3.7	4.5	4.9	5.5	6.5	7.5	9.8	12.3	14.5	21.5	25.5	29.5	37.5

Introduction:
1. This series boiler takes heat carrier oil as medium and uses the hot oil circulating pump force the medium to make Liquid circulation; then the thermal energy will be transmitted to the devices and back to the furnace to be reheated.
2. So the boiler can get higher working temperature at low pressure, and make a better usage of heat, it is a kind of safe boiler with high efficiency and low power consumption.
3. The fuel (oil, gas) light a fire by burner to produce flame and flame goes into the internal coil to form radiation heating surface.
4. Then it through rear coil tube forward rotated 180 ° into the tubes and to circulate into second interlayer, finally it will enter the atmosphere.

Features:
1. It is convenient to be adjusted, and can supply balanced heat to satisfy the hard work required to precise temperature.

2. Liquid circulationheating, less heat loss, high thermal efficiency.

3. Working medium can change volume when it was heated and release heat .and we have compensation technique measures in the system.

4. We have strictly technical measures to control air, water and other low volatile matter’s content of the working medium in thecirculation heating

5. The series boiler have advanced program control system, equipped with liquid level controller, pressure controller, temperature controller, and alarms to make sure the boiler work orderly and safe. So it is a kind of safe boiler with high efficiency and low power consumption.

Henan Sitong boiler Co., Ltd. is the national fixed-point production grade A boiler manufacture enterprise. Sitong boiler industrial park adjacent to national highway No.311 and Zhou-Shang expressway, the traffic is convenient, radiation far-reaching. Our company has perfect quality assurance system and advanced production technology, Rigorous scientific management mode and excellent service before-selling, sale and after-selling, Deep farce management concepts and the elegance of the enterprise culture. In the Trade Union, Our Company may be said that: brilliant achievements and well-established. It is also "Sitong boiler finds its way into every family, safety warm him, you and I.

Our major products are coal, oil, gas, steam (hot) water boiler, Electric heating steam (hot) water boiler, Environment and Energy-saving half gas boiler steam (hot) water boiler, Organic heat carrier furnace, Wastes incinerator, High, medium-temperature hot air stove and other 18 series of 100 specifications. Our company has strong development capacity, professional development engineer adopts CAD computer design, clay modelling and rapid prototyping technology, use the optical 3D scanner to engage in data acquisition engineering, and apply to auxiliary product appearance design, to complete test analysis and detection equipment and tools. Thus we make you enjoy the frontier technology of infinite scene from design and manufacturing of each procedure.

Our Company adhere to the science and technology as the guide, human as the support, quality as assurance and service continuously advance. and follow the management idea of "While a boiler leaves our factory , we make a friend, build a demonstration project and develop a piece of the market", 24 hours of experts substation telephone and computer network service, so as to provide sincerely help at any moment. We constantly win more market share and the trust of customers, which lay the foundation for the internationalization of "Sitong boiler".

Qualification massiness, enterprises culture full-bodied, technology-first, "Sitong boiler" walk the development of "Industrialization, Scalization and Branding", targeting technology commanding heights, building a "Yutong" brand, create the China boiler industry brilliancy hand in hand with the domestic colleague.
