OS Y Globe Valve DIN

OS&Y Globe Valve DIN

                                   OS&Y Globe Valve DIN

Pressure Temperature Rating

Working Pressure                  16bar

Testing Pressure                    Shell: 24bar

                                              Seal: 17.6bar

Working Pressure:                 -10C to 120C

Suitable Media:                     Water   Gas  &  Oil

Material Specification

Part                                    Material                                           EN Spec.

Body                               Cast Iron                                         EN-JL 1040

Bonnet                           Cast Iron                                         EN-JL 1040

Disc                               Cast Iron(65-300mm)                     EN-JL 1040
                                      Stainless Steel 420(15-50mm)        BS970 420S37

Disc Ring                     Stainless Steel 420                           BS970 420S37

Seat Ring                     Stainless Steel 420                           BS970 420S37

Stem                             Stainless Steel 420                          BS970 420S37

Hand Wheel                   Cast Iron                                         EN-JL 1040



                                                                  OEM is available.

OS&Y Globe Valve DIN

TIANJIN GALAXY VALVE CO.,LTD is an export-oriented Sino-US joint valve manufacturer established in 2004, which has strong capability of R&D, manufacturing, trading and service. It owned registered assets of 50 million RMB, and total assets of more than 100 million RMB. Tianjin Galaxy Valve has been certificated by ISO9001 QMS, European EC, and entitled to engage in import and export business, and has obtained the Type Approval certificates of DNV/ABS/CCS. It is also a member of China Valve Industrial Association, one of approved vendors of China Petrochemical market, and has obtained National Manufacture License of Special Equipment.

    Tianjin Galaxy Valves’ products covered kinds of butterfly valves, check valves, strainers, gate valves, ball valves, globe valves, balancing valves, with pressure range from 0.5–6.4Mpa, size from DN15-DN3000. The products have been widely used to national key projects, for example, Three Gorges Project, Jiuquan Satellite Launch Base, 2010 Shanghai World Expo water supply and drainage project, Tianjin Dagang Power Plant seawater cooling and desalination project, Guangxi Sino-French joint venture Laibin Power Plant, CNOOC Shanghai petrochemical project, Tianjin Zhonggang shipping projects. The products also have been widely exported to more than 30 countries and regions, such as USA, Canada, UK, France, the Netherlands, Italy, Australia, Souch Africa, Malaysia, Singapore, Hong Kong and so on.

    Tianjin Galaxy Valve treats quality as lifeblood of the company, and total quality management has been carried out. Quality is the key to make company stronger. Tianjin Galaxy Valve is always persevering in supplying perfect and satisfying valves by strict total quality. Tianjin Galaxy Valve sincerely wishes to establish good cooperation with world friends.
