Brand Name: GALA
Model Number: Fig.3101
Place of Origin: Tianjin, China (Mainland)
Brass NRS steam pressure seal api standard
gate valve class 150
FIG NO. | 3101 | |
Price Range | $2 ~ $87 | |
Valve Standard | Threaded to BS 21(ISO7)/ASME B1.20.1 | |
Size Range | 15mm (1/2") ~ 50 mm(2") | |
Working pressure | 200psi (13.8 bar)WOG Non-Shock 125psi (8.6 bar)Saturated Steam | |
Testing Pressure | Shell: 300 psi(20.7 bar)Hydrostatic | |
Seat: 220psi(15.1 bar) Hydrostatic 80 psi(5.5 bar)Air | ||
Screwed-In bonnet-Soild Wedge Disc Non-rising Stem.Integral Seat.Asbestos Free |
Material List | |||
Part | Material | ASTM | BS |
Body | Brass | B124 C38800 | 2874 CZ122 |
Bonnet | Brass | B124 C38800 | 2874 CZ122 |
Disc | Brass | B124 C38800 | 2874 CZ122 |
Stem | Brass Rod | B124 C38800 | 2874 CZ122 |
Packing | PTFE | ||
Packing Nut | Brass Rod | B124 C38800 | 2874 Cz122 |
Gland | Brass Rod | B124 C38800 | 2874 Cz122 |
Handle Wheel | Cast Iron | A48 No.35 | 1452 Gr.260 |
Tianjin Galaxy Valve Co.Ltd offers a wide range of products and systems in the field of valves for application ranging from
equipment for office buildings, fire fighting, heating, water works, sewerage, marine, industrial to top fluid control.
our certification show
Our product features are as follows:
1.Newly developed facilities ensure high and stable quality.
2.Enable to supply UL/FM valves.
3.Experienced technology
4.Excellent after-sale service to satisfy customers.
5.Sufficient capacity ensures prompt delivery.
6.Continuous quality improvement and new designs development.
7.Reasonable and stable price
8.Meets different countries standards,such as ANSI,DIN,BS etc.
Question 1: Does this product meet the lead free requirements?
Answer 1: No, it doesn't, but our design engineers are working on developing lead free products, we believe we can make it very soon.
Question 2: Can you send me a sample for test?
Answer 2: Yes, we can offer you a free sample, but the delivery cost will have to be paid by yourself.
Question 3: What is your target market?
Answer 2: Our products have been exported to 30+ countries and regions in global markets, such as U.S.A., Canada, UK, France, the Netherlands, Italy, Australia, South Africa, Malaysia, Singapore, Hong Kong and so on.
