Model

20GFT

Structure

integral

Exciting method

                                                 AVR Brushless

Rated Power (kW)

20

Rated Current(A)

36

Rated Voltage(V)

230/400, 3 phase

Rated Frequency(Hz)

50

Rated Power Factor

0.8 LAG

Overall dimension (L x W x H)(mm)

1650X720X1250

Net weight (kg)

680

Gas Engine

Model

NQ35D3

Type

In line, 4-stroke, electric control ignition, pre-mixed stoichiometry burn

Cylinder number

4

Bore x Stroke (mm)

98x115

Total displacement (L)

3.5

Rated Power (kW)

30

Rated Speed (r/min)

1500

Fuel type

Biogas

Control panel

NPT Brand 20KZY

LCD display

Circuit Breaker type

ATS SKT1-40

Control Module

Smartgen HGM6320

Operation language

English

Alternator

Model

XN162G

Brand

MBH( Germany brand)

Shaft

Single bearing

Rated Power (kW)

20

Rating(kVA)

25

Enclosure protection

IP23

Efficiency (%)

80.7

1.

10-500kw gas generator (Natural gas/Biogas/ LPG) with Quanchai, Deutz,Steyr,Ricardo, Weichai,brand engine etc. Low displacement

2.

Alternator  "STAMFORD" "MARATHON" "Leroy Somer" Brand 100% copper brushless alternator. Brushless excitation and "H" class insulation.

3.

Super silenced box, about 65d(B)A (L-7M)

4.

Longer life: Special design engine has longer life and overhaul time of 30000hours

5.

Moistureproof and derusting processing, effectively protect the generator from humid weather

6.

High quality steel

7.

Green environmental protection paint

8.

Cooling system: combined cooling water tank fitted to meet the requirement
of radiation at ambient temperature 40°C

9.

Advanced reasonable structure, high efficiency, low vibration and noise, smooth running, good reliability, easy handling. It is widly used in national defense, telecommunications, field construction, high-rise buildings, commercial buildings, industrial and mining enterprisers, oil fields,roads, ports, villages, banks, hospitals etc.

10.

ISO, CE approval

11.

Global warranty: 12months
