xps extruded polystyrene foam board

Price:

US 4-6 / Square

Min.Order Quantity:

100 Square Meter/Square Meters

Supply Ability:

per

Port:

shanghai

Place of Origin:

Payment Terms:

Brand:

Products Model:

Products Details
Company Profile

Quick Details

Packaging & Delivery

Packaging Details: 10 pieces packed with plastic.
Delivery Detail: --

Specifications

Xps Board

XPS foam has an innate combination of properties that make it one of the most efficient insulating materials available. The closed-cell structure, responsible for the foam’s excellent moisture resistance, also contributes to its high compressive strength and superior thermal performance.

ITEM	UNIT	SPECIFICATION
Density	Kg/m3	36~40
Thermal conductivity, 90 days, 10°C	W/mK	0.027~0.03
Compressive strength	kPa	≥300
Flexural Strength	Mpa	1.06
Tensile strength	kPa	≥300
Water absorption rate	%	≤1.00
Water vapor permeance	Ng/(m.s.pa)	≤3
Dimension Change Rate	%	≤2
combustion performance	~	Flame Retardancy B1
Temperature limits	deg.C	-50 to 75
Standard Size	mm	3000120020

XPS applications include:

Exterior Insulation Finish Systems (EIFS)
Insulating Concrete Form Systems (ICFs)
Structural Insulated Panels (SIPs)
Earth shelters
Swimming pools
Recreational vehicles
Agricultural buildings
Low temperature spaces
Ice rinks
Precast concrete systems
Plaza decks
Highway insulation
Airport runway insulation
