SGI10-16S-SGN19-22S,014-0147S Danfoss Sight glass

SGI10-16S-SGN19-22S,014-0147S Danfoss Sight glass

SG is sight glasses for low pressure application
(Max Working Pressure 500 psig).
SG is available with flare, solder and socket
connections, and with and without moisture
indicators.
SG and SGR, without moisture indicator, are
mainly used to indicate the condition of the
refrigerant in the liquid line or the flow in the oil
return line from the oil separator.
SGI / SGN and SGRI / SGRN are equipped
with sensitive indicators that reflects a color,
which depends on the moisture content in the
refrigerant.

Provides fast and easy indication of:
– High system moisture content
– Lack of subcooling or low system charge
– Liquid level in receiver
(vessel mount versions only)
• Oil level in compressor
(vessel mount versions only)
• Two Indicator types:
– Type “I” – provides optimal moisture
indication for refrigerants with mineral oil,
e.g. R22
– Type “N” – provides optimal moisture
indication for refrigerants: R22, R134a,
R404A, R407C, R507, R407A, R407F, R448A,
R449A, R450A, R452A, R513A
• All indicators are dirt resistant
• Available in both inline and vessel mount
versions
• Hermetically sealed, tempered glass for easy
viewing
• Available in flare / flare, solder / solder
connection or socket type
