DERON EVI air to water heat pump

FOB Price:

US 3,520-3,870 / Piece

Min.Order Quantity:

1 Piece/Pieces

Supply Ability:

1000 Unit/Units per Month

Port:

Guangzhou

Place of Origin:

Guangdong, China (Mainland)

Payment Terms:

T/T

Brand:

DERON

Products Model:

DE-92W/DW

Products Details
Company Profile

Quick Details

Brand Name: DERON

Model Number: DE-92W/DW

Place of Origin: Guangdong, China (Mainland)

Packaging & Delivery

Packaging Details: plywooden case
Delivery Detail: Shipped in 35 days after payment

Specifications

DERON EVI air to water heat pump

Model: DE-92W/DW

This series of air source EVI heat pump is is specially designed for house heating in chilly climate areas, it can be applied to sanitary hot water for bathroom or central heating for house where safe working at temp -25 deg.C to 45deg.C.

Adopting the most advanced low- temperature Enhanced Vapors Injection compressor technology.

1)Operation range: -25°C~+45°Cambient temperature.

2)Power supply: 380V/3ph/50(60)Hz.

3) Reliable EVI compressor with /R417a/R407c refrigerant.

4) Extremely compact structure and good demount ability.

5)Galvan magnetic reverse valve and expansion valve are included.

6)Water flow switch is optional .

7) Water exchanger equipped with high efficiency tube in tube& plate heat exchanger

8) Air exchanger(fins-coil) with hydrophilic coating.

9) Adjustable defrosting according to different weather conditions (with four way valve inside).

10) Thermostatic heating element for evaporator anti-frosting protection

12) Optional auxiliary electric heater control function is inside, as a standby of heat pump.

13) Anti-corrosion case: coating case or stainless steel case; all case with stainless steel bolts and nuts.

Model		DE-92W/DW	DE-180W/DW
Power supply	(V/ph/Hz)	380/3/50	380/3/50
*Heating capacity	(kW)	41.5	82
*Heating capacity	(BTU)	141591	279770
*Rated power input	(kW)	9.2	18
*Water feed speed	(L/h)	850	1665
*Test condition		*Ambient temp.(Dry Bulb/Wet Bulb): 20°C /15°C, Water temp.(in /out): 15°C/55°C.
**Heating capacity	(kW)	32.5	65
**Heating capacity	(BTU)	110885	221769
**Rated power input	(kW)	8.3	16.2
**Test condition		** Ambient temp.: 7°C, Water temp.(in /out): 30°C/35°C.
***Heating capacity	(kW)	28.2	57
***Heating capacity	(BTU)	96214	194475
***Rated power input	(kW)	8.2	16
***Test condition		***Ambient temp.: 2°C, Water temp.(in /out): 30°C/35°C.
***Heating capacity	(kW)	20.5	41
***Heating capacity	(BTU)	69943	139885
***Rated power input	(kW)	7.6	14.5
***Test condition		***Ambient temp.: -10°C, Water temp.(in /out): 30°C/35°C.
Refrigerant		R407C
Refrigerant weight	(g)	10400	20800
Compressor	(type)	Scroll
Compressor	(number)	2	4
Fan	(type)	Axial flow type with Nylon fan blade
	(discharging)	Vertical
	(number)	1	2
	(air flow)(m3/h)	11000	7400*2
Evaporator		Aluminium/Cu lamellar tube evaporator
Condenser (heat exchanger)		Coaxial coil heat exchanger (Copper Tube -in- Steel Tube)
Economizer (heat exchanger)		Stainless steel plate
Throttling device		Emerson thermal expansion valve
Controller		Indoor Digital Controller
Required water flow rate	(m3/h)	8	16
Water connection		G1-1/4"	G2"
Required tank cubage	(t)	7-10	15-20
Max. current	(A)	25	49
Noise	dB (A)	≤65	≤68
Level again electric shock		I	I
Water proof		IPX4	IPX4
Max. water temp.	(°C)	60	60
Operation temp. range	(°C)	-25-45	-25-45
Net weight	(kg)	320	680
Net size-(LWH)	(mm)	1270X1000X1425	2460X1315X2070

1. We are a nationally high-tech company in China with technical cooperation with Germany, focusing on researching and producing environmental energy-saving heat pump units, which are mainly used in guesthouses, hotels, schools, offices, factories, hospitals and family villas.

2. Our company is among the earliest companies to establish the heat pump R&D center in China, and has our own heat pump laboratory, which lead to the breakthrough that the use of heat pump at -25 deg.C low temperature zone is possible. Moreover, we made it practical to test the air source, water source or ground source heat pumps.

Our company has set up our heat pump technology transfer center of Guangzhou Institute of Energy Conversion, Chinese Academy of Sciences and Sino-Germany Magnetically Levitated Heat Pump R&D Center. Our company is also the strategic partner of American Emerson Copland Company.

3. Our company has obtained the license of national industrial production. Our products have passed ISO9001 quality system, and gained national CCC compulsory certification, CE certificate of the EU, and TUV as well as SGS.

4. Deron is regarded as "Top Ten Heat Pump Water Heater Brands" in China and 2010 Asian Games Venues are equipped with Deron heat pump systems to provide hot water for athletes.
