Home > Products > Refrigeration Equipment > Cold Storage

industral wine chiller cold room

FOB Price:

US 9,500-18,000 / Set

Min.Order Quantity:

1 Set/Sets

Supply Ability:

10000 Set/Sets per Year

Port:

Qingdao,Shanghai

Place of Origin:

Shandong, China (Mainland)

Payment Terms:

L/C,D/A,D/P,T/T,Western Union,MoneyGram

Brand:

ONLYKEM

Products Model:

OKM1223

Products Details
Company Profile

Quick Details

Brand Name: ONLYKEM

Model Number: OKM1223

Place of Origin: Shandong, China (Mainland)

Packaging & Delivery

Packaging Details: wind chiller cold room with wooden package with pallet
Delivery Detail: within 10 days after receiving deposit

Specifications

industral wine chiller cold room

wind chiller cold room application

Our modular cold storage series is an integrated family of sandwich panels designed for quick cold room assembly. The panel configuration has been reduced to a minimum, so the overall effect is to offer the clients maximum design possibilities for cold rooms with a minimum amount of panels required on the site. All products from the modular range can be easily assembled without the need for special tools.

Specification for PU foam frozen fish blast freezer storage

Dimension	Length x width x height customized
Panel	Polyurethane foam insulation panel,38~42kg/m3, fire resistance
Thickness of panel	75mm,100mm, 120mm,150mm,180mm,200mm optional
Surface steel	color steel or stainless steel option
Panel Connection	cam lock connection
Door type	sliding door, hinged door option, size can be customized
Cold room temperature	-35~+15'C
Refrigeration unit	Bitzer Tecumseh, Copeland compressor for options
refrigerant	R134a, R404a, R507c
voltage	380V/3ph/50~60hz, 230V/3PH/50~60HZ.
application	Seafood, meat quick freezing, and fruit and vegetable fresh keeping

1. Polyurethane foam panel advantage and specification:

Thickness(mm)	Temperature application(°C)	Weight(kg/m²)	R-value(m².k/w)
50	Above -5'C	12.8	2.28
75	above-15'C	13.8	3.42
100	above-15'C	14.8	4.55
120	above-15'C	15.7	5.6
150	above-15'C	16.8	6.82
200	above-15'C	18.8	9.12

Tolerance Control

Length(mm)	Tolerance(mm)			Straightness
Length(mm)	Length	Width	Thickness	Straightness
500~3600	±3	0~3	±1	1/500
3600~6000	±4	0~3
6000~12000	±6	0~3

Our Polyurethane foam panel advantage:

1. reliable raw material, use galvanized steel cam lock, best color steel.

Reliable cold room raw material specification.

2. Cold room door

sliding door and hinged door, 100mm and 150mm for option, special heater for low temperature application.

Safety: Emergency device keep your all stuff safety!!

3. Refrigeration cool room system

1. Over 10 years manufacturing experience, products sell well in many countries, full experience support to give you most suitable system

2. Compressor, we use all new origin famous brand, Bitzer, Copeland, Tecumseh, Maneruop or brand you appointed. other accessories are same,

3. Professional engineer support, can assist you from design to after sale service, choose us, it is beginning of your new sucess!!

Packaging & Shipping

OnlyKem Technology Co., Ltd. is a new company just founded in 2009, but we are not a newcomer to refrigeration industry. We have more than 10 years working experience in refrigeration field. We are young, energetic, innovative and confident!
We don't want to be a successful businessman, we would like to be skilled craftsman. The idea of making a perfect machine is always fascinating for us. Now our products are in South America, Asia, Middle-east, some countries of Europe, Oceania and Africa. Our stable quality, competitive price and immediate service let us possess more and more long term cooperation customers.
In future, we believe that all kinds of our products can stay the fresh life for you, including of our cold room, evaporator, condenser and condensing units. We would like to achieve this dream with you together and let more and more people enjoy quality life.
Join Us, Enjoy Life!
www.coldroomplus.com

Basic Information

Business Type: Manufacturer,Trading Company
Main Products: Air Cooled Evaporator,Cold Room,Condensing Unit,Condenser,Cold Storage
Location: Shandong, China (Mainland) Asia
Year Established:

Trade Capacity

Accepted Delivery Terms: FOB,CFR,CIF,EXW,CIP
Accepted Payment Currency: USD,RMB,EUR
Accepted Payment Type: L/C,T/T,Western Union,MoneyGram,Escrow,Cash
Nearest Port: Shanghai,Ningbo,Guangzhou
