Black color DC INVERTER Air to Water Heat Pump 7KW

FOB Price:

Open price

Min.Order Quantity:

1 Set/Sets

Supply Ability:

500 Set/Sets per Month

Port:

SHUNDE; GUANGZHOU; SHENZHEN

Place of Origin:

Guangdong, China (Mainland)

Payment Terms:

T/T

Brand:

OEM

Products Model:

KS70-DC1

Products Details
Company Profile

Quick Details

Brand Name: OEM

Model Number: KS70-DC1

Place of Origin: Guangdong, China (Mainland)

Packaging & Delivery

Packaging Details: 1. Whole set unit is packed nicely in a PE bag. Packing by Anti-collision protection + 5 Layer carton + wooded Case (For LCL only). 2. Spare parts & instruction sealed in the pack. 3. Customized packing is available. 4. We are always working hard on the most reliable packing in order to help you get the Perfect products.
Delivery Detail: Shipped in 35 days after payment

Specifications

DC INVERTER R410A AIR TO WATER 7KW (split type)

Designed as Split Type , Indoor Unit and Outdoor Unit be Connected by Copper pipe,Installation With Simple,Flexible and Conveniently ,The Indoor Unit can be Installed in Kitchen, Bathroom or basement, Ensuring less Energy loss, Also Prevent Water Pipes From Freezing in Cold Winter and sun Exposure in hot Summer.
Inside unit include: LCD controller, three way valve, flow switch, WILO/Grundfos water pump, plate heat Exchanger and inside connection
Outside unit with DC inverter R410a, electrical expansion valve, compressor heater, bottom heater. with remote control function. With different control languages.

SERO E-STAR (air to water with DC INVERTER series)

A high flexible, energy efficient home heating system that extracts the heat from the outside air, raises this heat to a higher temperature and then distributes warmth around the home through high quality heating units. At the heart of the system lies an air to water heat pump. Because of this advanced technology, three quarters of the heat generated by the SERO E-STAR system is absolutely free of charge! The E-STAR air to water heat pump is today's answer to the current and future problems associated with conventional heating systems, such as, increasing primary energy costs and an unacceptably high environmental impact.

Our system have more advantage in defrosting.

There are 2 pieces additional electrical hearters in outdoor unit. One is compressor heater, the second one is buttom heater. They are very helpful to defrosting.

Specification of DC inverter series(Air to water)

Indoor unit

Model			KS50-DC1	KS70-DC1	KS90-DC1	KS120-DC1	KS150-DC1
Function			Heating only (Cooling and heating is optional.)
Dimensions	WxHxD	mm	450X550X255			550X650X255
Weight		kg	18	19	22	27	32
Leaving water temperature range	heating	°C	20-60
	cooling	°C	5-35
Hot water		°C	20-60
Water three way valve			Yes
Heat exchanger			Stainless steel plate
Water pump			Yes
Shell material			Epoxy polyester painted galvanised steel
Additional electrical heater		KW	2			3
Power supply		V/Hz/Ph	230/50/1

Standard model is heating only. Cooling and heating is optional.

Outdoor unit

Model			KS50-DC1	KS70-DC1	KS90-DC1	KS120-DC1	KS150-DC1
Dimensions	WxHxD	mm	840x590x290	840x700x315	880x780x360	830x1230x310	930x1250x310
Nominal Capacity	heating	kW	5.60	7.41	9.32	12.94	14.80
Nominal Capacity	cooling	kW	5.12	6.70	8.53	11.20	13.90
Nominal input	heating	kW	1.31	1.77	2.27	3.17	3.60
Nominal input	cooling	kW	1.87	2.42	3.02	4.13	5.10
COP			4.27	4.19	4.11	4.08	4.11
EER			2.74	2.77	2.82	2.71	2.73
Compressor		type	Rotary	Rotary	Rotary	Scroll	Scroll
		Quantity	1	1	1	1	1
		Brand	Sanyo	Sanyo/Panasonic	Sanyo/Panasonic	Sanyo/Hitachi	Sanyo/Hitachi
Operation ambient range		°C	-20- 43
Sound pressure level	heating	dBA	51	52	54	56	56
Sound pressure level	cooling	dBA	52	53	54	57	57
Weight		kg	48	52	68	90	110
Refrigerant charge	R-410A	kg	0.82	1.15	1.4	2.5	3.4
Power supply * optional		V/Hz/Ph	230/50/1			230/50/1 230/50/3 *400/50/3	230/50/1 230/50/3 *400/50/3

Measurement condition: A7/W35(heating mode), A35/W7(cooling mode) .

* Get more details please Email to us or contact our company.

Foshan Sero Electronical Appliances Co., Ltd.
Founded on 1997,Located in Shunde,Foshan Guangdong ,China. Over 220 employees.
Factory area:10000 sq. m. .
We concertrated on manufacture heat pump product and high end air conditioner.
Vietnam branch factory located in Paiphong.
Financial office located in HONGKONG.

Product Details:
*Household & residential air-conditioner series: DC inverter split type, portable type, split wall-mounted type, window type, split floor-standing type, duct split type, dual & multi split wall-mounted type and cassette type. (capacity from 9000btu to 48000btu, over 200 models).

*Heat pump water heater series: swimming pool heaters & chillers, heat pump water heaters - all-in-one; heat pump water heater-split type, floor heater (water source, ground source or air source); machine double as air-conditioner (over 80 models).

*Small commercial air-conditioner series: DC inverter dual & multi split wall-mounted type; DC inverter dual & multi duct type, DC inverter dual & multi cassette type.

VRV series, water chiller and coil unit (fan coil high wall, water cassette); high static pressure ducted type (over 100 models).

*Special air conditioner series: solar energy heat pumps, elevator air conditioners, marine air conditioners, industrial chillers, quick connect stainless steel pipe - AC package AC. T3 series (over 50 models).
