10m3/min Air Flow Water Cooling 40Bar Oil Free Air Compressor for Bottle Blowing

FOB Price:

Get Latest Price

Min.Order Quantity:

1 Set/Sets

Supply Ability:

200 Set/Sets per Quarter

Port:

Qingdao

Place of Origin:

Shandong, China (Mainland)

Payment Terms:

L/C,D/A,D/P,T/T,Western Union,MoneyGram

Brand:

Mgreenbelt

Products Model:

AE-10.0/40

Products Details
Company Profile

Quick Details

Brand Name: Mgreenbelt

Model Number: AE-10.0/40

Place of Origin: Shandong, China (Mainland)

Packaging & Delivery

Packaging Details: Plastics Industry Blow Molding PET Compressors & Dryers In Plywood Case.
Delivery Detail: 25 days

Specifications

10m3/min Air Flow Water Cooling 40Bar Oil Free Air Compressor for Bottle Blowing

Description of Goods

Oil Free High Pressure Air Compressor is used for making cosmetic bottles. The compression air is 100% oil free, ensuring the safety of plastic cosmetic bottles.

Technical Parameters of Air Compressor For Bottle Blowing

Model	AE-10.0/40
Motor power	120kw
Air compressor working voltage	220v,380v,415v,440v,460v,480v
Air pressure	40bar (40kg/cm²)
Oil free air displacement	10.0m³/min
Shaft power	105kw
Outlet air size	DN40
Cooling water inlet and outlet	1-1/2"
Weight	4500KGS
Industrial air compressor size	3620x2100x2000mm
Water consumption	20T/hour

Features of Silent Plastic Bottle Blowing Air Compressor

1. Complete 304 stainless steel pipeline

Long operation life, excellent anti-corrosion, high temperature resistance, high intensity.

2. Double-acting cylinder

Achieve balanced compression and low energy consumption.

Minimize leakage and optimize efficiency.

Lower compression temperature.

Longer service life of components.

Optimized adjustment.

3. Converter technique application

Eliminate or reduce the operation time of compressor while unloading, accurately tracking the gas demand of users and meeting requirements of different productions.

4. Efficient water cooling system

5. Primary screw air end discharge pressure 1.0MPa-1.2MPa.

6. Smaller inter-stage compression ratio, energy-efficient.

Self-design Piston Air Compressor Air End (Booster compression air to 40bar)

High Efficient Water Cooling System

Adopt water cooling to cool down the cylinder and stuffing. The compression temperature is under 130°C, greatly reducing the abrasion and enabling the unit to be installed in a narrow space and hostile environment without being affected.

Cooling tower radiating heat of air compressor.

Structure of Stationary 40 Bar Air Compressor

Low Noise Air Compresor

Air Compressors Used in Factories

If you need such air compressor, contact with me:

Lean

Mobile: 008617686681006

E-mail: cncompressors(at)gmail.com

Established in the year 2003, we, " Mgreenbelt Machinery Co., Ltd," are engaged in manufacturing, exporting and supplying Chillers, Cooling Towers, Heat Exchangers and Components. Our range is appreciated by the clients based in various parts of China and world for its characteristics, such as robust structure, longer service life and high performance. The durable products are manufactured by experienced workers, using graded alloys and qualified electronic components. Further, for clients' covenience, we undertake the designing and turnkey projects for the devices.

At the sound manufacturing facility, we undertake the production of high performance machines. The quality controllers test the range, to ensure that it is in compliance with the degree of prevailing quality standards. Moreover, we also offer after sales services to ensure all the queries to be handled within the shortest time. We would like to grow and improve by anticipating consumers' needs, offering a better solution than competitiors and supporting customers to be confident of getting fast answers of requirement.

We have been successfully in offering machines to projects of Packaged Equipment and System, Automobile Components Producing System, Food Making, Bakery, etc. to clients from domestic, USA, Canada, Australia, Ecuador, Sudan, Russia, South Africa, Dubai, Israel, India, Philippine, Singapore, Vietnam, Thailand and Korea, etc.
