Brand Name: Gree
Model Number: GMV-H200WL/B
Place of Origin: Guangdong, China (Mainland)
2016 New Arrival Multi Type Central Air Conditioner
1.Gree power series characteristic and advantages:
(1)Large capacity small body, change household central air conditioning installation constrained
(2)Smaller and flexible indoor unit, meet the decoration requirement
(3)Two small compressor combination, saving more power
(4)Silent to 22dB(A)
(5)Comfortable and health, not only a air conditioning, is a air housekeeper
(6)Intelligent operation, enjoy the management of air conditioning
(7)More reliable performance.
2.GMV-H200WL/B outdoor unit main specifications:
Model | Cooling capacity |
Heating capacity |
Noise | Power supply |
Rated power | Connection pipe | Connection way |
Net | ||
Cooling | Heating | Wind pipe | Fluid pipe | |||||||
kw | kw | dB(A) | kw | kw | mm | mm | kg | |||
GMV-H200WL/B | 20 | 23 | 60 | 380v- 3N-50Hz |
6.2 | 5 | 22.2 | 9.52 | Sealing-in | 175 |
GMV-H224WL/B | 22.4 | 25 | 60 | 7.2 | 7.1 | 22.2 | 9.52 | Sealing-in | 175 | |
GMV-H250WL/B | 25 | 27 | 61 | 7.4 | 8.9 | 22.2 | 9.52 | Sealing-in | 185 | |
GMV-H280WL/B | 28 | 30 | 61 | 8.7 | 10.5 | 22.2 | 9.52 | Sealing-in | 185 |
3.Application:
FAQ:
1.Whats’s household central air conditioning?
It is a host to bring many sets of terminal equipment, can provide more room at the same time
cooling/heating and air conditioning system of air conditioner, also is a kind of between large
central air conditioning and common household split type wall-mounted air-conditioner, fission cabinet wall hung in the air conditioning, fission cabinet air conditioning a
small central air conditioning.
2.When is the most appropriate to choose the household central air conditioning?
It is better to choose the air conditioning before decorating.
3.The buying process of the household air conditioning:
Preliminary decorate plan - the chosen of household central air conditioning, decided to buy
which type and brand of air conditioning- handing in a room - field exploration to determine the
final plan, signing - after installation of air conditioning equipment installed in - air
conditioning test - home decoration, installation finally tuyere, final testing
4.Contact information:
Just tell us if more detail needed.
