Brand Name: LYTTE, OEM
Model Number: HGM, HGZ
Place of Origin: Shandong, China (Mainland)
Condensing Unit for Refrigerant Cold Room
1. Product description
This series products feature open type structure with hermetic Danfoss Maneurop compressor, that is liquid shock proof. The units are air cooled , no cooling system is needed.
2. Main components
Excellent brand refrigeration parts are employed for all products:
Hermetic Danfoss Maneurop compressor;
Copper tube & aluminum fin type heat exchanger;
Air Cooled Condensing Unit Specifications:
Model Specifications:
H G M - 18
H-Temperature, H:-5~5°C; M:-18~-15°C(R22), -25°C~ -15°C(R404a)
G-Compressor Brand:Danfoss Maneurop
M-Refrigerant Type, M:R22; Z:R404a
18-Compressor Model No.
Model Overview:
1. Refrigerant: R22
1.1 Middle and High Temperature:-5°C~ 5°C Models: HGM18---HGM160
1.2 Middle and Low Temperature:-18°C~ -10°C Models: MGM28---MGM160
2. Refrigerant: R404A
2.1 Middle and High Temperature:-5°C~ 5°C Models: HGZ18---HGZ160
2.2 Middle and Low Temperature:-25°C~ -15°C Models: MGZ28---MGZ160
Model Details
1. HGM Series: Air Cooled R22 Condensing Units
1.1 Temperature:-5°C~ 5°C
Design Working Condition: Evaporation Temperature -7°C; Environmental Temperature 35°C;Suction Superheat 10°C.
1. MGM Series: Air Cooled R22 Condensing Units
1.2 Temperature:-18°C~ -10°C
Design Working Condition:Evaporation Temperature -23°C; Environmental Temperature 35°C;Suction Superheat 10°C.
