Brand Name: senphus
Model Number: SHHM150
Place of Origin: Jiangsu, China (Mainland)
Custom Heating Cable for Floor Heating
Senphus company can accept any custom heating cable.
Senphus heating cable are specialists in the supply, design and installation of senphus electric underfloor heating systems for domestic, commercial and industrial use. Senphus underfloor heating can supply a total solution for any type of electric under floor heating.
Senphus underfloor heating cable specification
| Size | Power/W | Resistance | Length(m) | The power line length | Out Diameter |
| SHDN-20-15M(A) | 300 | 176.3 | 15 | 3C 0.5mm2 L=2M black | 5.0±0.1mm |
| SHDN-20-25M(A) | 500 | 105.8 | 25 | 3C 0.5mm2 L=2M black | 5.0±0.1mm |
| SHDN-20-30M(A) | 600 | 88.2 | 30 | 3C 0.5mm2 L=2M black | 5.0±0.1mm |
| SHDN-20-35M(A) | 750 | 75.6 | 35 | 3C 0.75mm2 L=2M black | 5.0±0.1mm |
| SHDN-20-42.5M(A) | 850 | 62.2 | 42.5 | 3C 0.75mm2 L=2M black | 5.0±0.1mm |
| SHDN-20-60M(A) | 1200 | 44.1 | 60 | 3C 0.75mm2 L=2M black | 5.0±0.1mm |
| SHDN-20-80M(A) | 1600 | 33.1 | 80 | 3C 1.0mm2 L=2M black | 5.0±0.1mm |
| SHDN-20-90M(A) | 1800 | 29.4 | 90 | 3C 1.0mm2 L=2M black | 5.0±0.1mm |
| SHDN-20-100M(A) | 2000 | 26.5 | 100 | 3C 1.0mm2 L=2M black | 5.0±0.1mm |
| SHDN-20-120M(A) | 2400 | 22 | 120 | 3C 1.5mm2 L=2M black | 5.0±0.1mm |
| SHDN-20-140M(A) | 2800 | 28.9 | 140 | 3C 1.5mm2 L=2M black | 5.0±0.1mm |
| SHDN-20-160M(A) | 3200 | 16.5 | 160 | 3C 1.5mm2 L=2M black | 5.0±0.1mm |
| Type | Voltage | Power(W) | W/M | Length(M) | Resistance | OD(mm) |
| SHDN-SS-12W (F) 16.7M | 230V | 200 | 12 | 16.7 | 264.5 | 2.4 |
| SHDN-SS-12W(F) 25M | 230V | 300 | 12 | 25 | 176.3 | 2.4 |
| SHDN-SS-12W (F) 33.3M | 230V | 400 | 12 | 33.3 | 132.3 | 2.4 |
| SHDN-SS-12W(F) 41.7M | 230V | 500 | 12 | 41.7 | 105.8 | 2.4 |
| SHDN-SS-12W(F) 54.2M | 230V | 650 | 12 | 54.2 | 81.4 | 2.4 |
| SHDN-SS-12W(F) 66.7M | 230V | 800 | 12 | 66.7 | 66.0 | 2.4 |
| SHDN-SS-12W (F) 83.8M | 230V | 1000 | 12 | 83.3 | 53.0 | 2.5 |
| SHDN-SS-12W (F) 104.2M | 230V | 1250 | 12 | 104.2 | 42.3 | 2.5 |
| SHDN-SS-12W(F) 125M | 230V | 1500 | 12 | 125 | 35.3 | 2.5 |
| SHDN-SS-12W(F) 150M | 230V | 1800 | 12 | 150 | 29.4 | 2.5 |
| SHDN-SS-12W(F) 166.7M | 230V | 2000 | 12 | 166.7 | 26.5 | 2.5 |
| SHDN-SS-12W (F) 208M | 230V | 2500 | 12 | 208 | 21.2 | 2.5 |
| SHDN-SS-12W (F) 250M | 230V | 3000 | 12 | 250 | 17.6 | 2.5 |
Senphus underfloor heating are an approved supplier of the full range of senphus matting and cable products.
