Double sided aluminum foil composite phenolic foam duct panel

FOB Price:

US 4.5-7 / Square Meter

Min.Order Quantity:

1000 Square

Supply Ability:

10000 Square per Meter/Square

Port:

Qingdao

Place of Origin:

Shandong, China (Mainland)

Payment Terms:

L/C,D/P,T/T

Brand:

HUAHAI

Products Model:

Products Details
Company Profile

Quick Details

Brand Name: HUAHAI

Model Number: HH

Place of Origin: Shandong, China (Mainland)

Packaging & Delivery

Packaging Details: Export standard plastic bag and carton,10pcs per pack
Delivery Detail: with 7 days after receivin the deposit money

Specifications

Huahai Phenolic air duct panel take phenolic foam as core. Both sides with aluminum foil or one side with color steel, the other side with aluminum foil or one side with GL the other side with aluminum foil or both side with color steel .

Performance index

Density	55-68kg/m3
Thermal conductivity	0.025w/m.k
Aluminum foil thick	60-80micron
color steel thick	0.18-0.2mm
Compressing strength	300k pa
Bending strength	1.05m pa
Non-combustible	class “O”
Water absorption	1.9%
Max. Smoke density	2%
Work temperature	-150°C to 150°C
size	2950/3950120020/25/30mm

Advantage

1. Excellent flame retardant properties, open flame only carbonation does not burs.

2.It's of good appearance , beautiful colors, light weight, high strength ,and easy installation.it's fireproof, water-proof and of good insulation property.By using this material, the user can save a lot of costs and time .

3.This air duct panel is made of pu foam, it adopts new non-fluoride foaming technology, adds harmless auxiliary agents , uses special resin to change features, and through aluminium foil surface chemical treatment. The double sides are embossed aluminium foil ,and the inner layer is made of flame-retardant phenolic foam materials .

Acessories

Main export countries and regions.

Our products have been exported to more than thirty countries and regions such as USA , Australia, Korea, Cyprus, Iran, Singapore, India, Thailand, Myanmar, Norway and Canada, Trinidad and Tobago,Peru,Japan, Guam, Ghana,Laos, UAE, Indonesia, Taiwan, Panama, Philippines, etc.

Thengzhou City Huahai New Thermal Insulation Material Co.,Ltd

Established in 2002, focuse on Phenolic foam insulation board, PU sandwich cold storage panel , PU roof and wall panel and accessories. There are 9 automatic production lines in factory, capacity 22000 m² per day .

HUAHAI is the biggest base for phenolic foam research and development in China

We sincerely welcome all customers to contact us for business and cooperation.

Established in 2002 Tengzhou Huahai Group is a high and new technology enterprise which is located in Tengzhou City,Shandong Province China.Our group covers an area of 66,670 square meters. and has 612 employees.
Our main products are, HVAC Phenolic foam air ducting panel ,Heat resistant insulation board Pre-insulated PU air ducting panel,PU sandwich panels and PU Cold storage panel .
The primary members of the group include
Tengzhou City Huahai New Insulation Materials Co., Ltd.
Tengzhou Jutong Import & Export Trade Co.,ltd
Shandong Plant Co.,ltd
Huahai New Thermal Insulation Materials Co., Ltd. established in 2002, developed Phenolic foam composite board continuous production process with the cooperation of some universities and institutes. The new process ranked among the first in the world and it surmount the traditional moulding production process and was the first one in China which can produce continuously. The production line was praised as "the first line in China" by "China Building Materials News" and the experts. Moreover, aluminum foils and phenolic foam composite boarsd have passed the evaluation of provincial level scientific and technological achievement test. We have attained IS09001:2000 Quality Management System Certification and IS014001:2004 Environmental Management System Certification and have been elected as the standing committee member of China Thermal-Sound-Insulation Material Association.
We will follow the spirit of "build environmentally friendly home" to produce insulation and fireproof composite boards with advanced technology. We will build a phenolic city and make Huahai Group the largest phenolic foam production base in China with the top technology, quality and service.
