LQ3G Three Screw Heat Pump Heat preserving bitumen pump

LQ3G Three Screw Heat Pump Heat preserving bitumen pump

FOB Price:

US 99-9000 / Piece

Min.Order Quantity:

1 Piece/Pieces

Supply Ability:

20 Piece/Pieces per Month

Port:

Ningbo/Shanghai

Place of Origin:

Zhejiang, China (Mainland)

Payment Terms:

L/C,T/T,Western Union

Brand:

YONJOU

Products Model:

LQ3G

Products Details
Company Profile

Quick Details

Brand Name: YONJOU

Model Number: LQ3G

Place of Origin: Zhejiang, China (Mainland)

Packaging & Delivery

Packaging Details: export plywood case
Delivery Detail: 15 days after receiving payment (according to order quantity)

Specifications

LQ3G Three Screw Heat Pump

LQ3G Three Screw Pump can transmit lubricating oil without particle, non-corrosive oil. The viscosity can be 3.0-760 mm2/s. High viscosity medium can be pumped after overheating. But the temperature not exceed to 350 degree.

Advantage:

Simply constructer,

Reliable capacity,

High speed allowable,

Lowest noise,

High efficiency,

Long operation life,

Self priming function

Usage:

1. Widely used in machine, petroleum, steel-making, power, chemical fiber, food and shipbuilding, etc.

2. Fuel oil, rubricating oil, hydraulic oil, crude oil, bitumen and similar rubricating liquid.

3. LQ3G Progressing Cavity Pump can be used as rubricating pump, hydraulic pump, boost pump, petrol pump and dispensing pump.

Data Table:

Model	Capacity (m3/h)	Pressure (bar)	Speed (r/min)	Power (kw)	Inlet Dia. (mm)	Outlet Dia. (mm)
Model	Capacity (m3/h)	Pressure (bar)	Speed (r/min)	Power (kw)	Inlet Dia. (mm)	Outlet Dia. (mm)
LQ3G45*2-46	4.5	6	960	1.5	40	40
	4.2	10	960	2.2
	6.5	6	1450	2.2
	6.2	10	1450	3
LQ3G50*2-46	8	8	960	2.2	50	50
	8.6	10	960	3
	15	6	1450	4
	14	10	1450	5.5
LQ3G80*2-46	17	8	960	7.5	80	65
	25	6	1450	7.5
	25	10	1450	11
LQ3G90*2-46	34	8	960	11	100	100
	55	6	1450	15
	53	10	1450	18.5
LQ3G100*2-46	48	8	960	15	125	125
	75	6	1450	18.5
	72	10	1450	22
LQ3G110*2-46	62	6	960	18.5	150	150
	60	10	960	30
	100	6	1450	30
	98	10	1450	45
LQ3G120*2-46	85	6	960	22	200	200
	80	10	960	37
	130	6	1450	37
	125	10	1450	55
LQ3G150*2-46	160	6	960	45	300	250
	155	10	960	75
	252	6	1450	75
	240	10	1450	90
