Brand Name: YONJOU
Model Number: IHF
Place of Origin: Zhejiang, China (Mainland)
>>> Internal Structure
>>> Summarize
>>> Main Application
Liquids, waste water, the random density acid, alkali and strong oxidant and organic solvent etc.
>>> Data Table
Model | Inlet | Outlet | Flow | Head | Power | Rotary speed | (NPSH)r |
(mm) | (mm) | (m3/h) | m | kw | r/min | m | |
IHF50-32-125 | 50 | 32 | 12.5 | 20 | 2.2 | 2900 | 3 |
IHF50-32-160 | 50 | 32 | 12.5 | 32 | 4 | 2900 | 3 |
IHF50-32-200 | 50 | 32 | 12.5 | 50 | 7.5 | 2900 | 3 |
IHF65-50-125 | 65 | 50 | 25 | 20 | 3 | 2900 | 3.5 |
IHF65-50-160 | 65 | 50 | 25 | 32 | 5.5 | 2900 | 3.5 |
IHF65-40-200 | 65 | 40 | 25 | 50 | 11 | 2900 | 3.5 |
IHF80-65-125 | 80 | 65 | 50 | 20 | 5.5 | 2900 | 4 |
IHF80-65-160 | 80 | 65 | 50 | 32 | 11 | 2900 | 4 |
IHF80-50-200 | 80 | 50 | 50 | 50 | 15 | 2900 | 4 |
IHF100-80-125 | 100 | 80 | 100 | 20 | 11 | 2900 | 4.5 |
IHF100-80-160 | 100 | 80 | 100 | 32 | 15 | 2900 | 4.5 |
IHF100-65-200 | 100 | 65 | 100 | 50 | 30 | 2900 | 4.5 |
>>> Performance Curve
>>> Mass Production
The goods are packed in new strong cases suitable for long distance ocean and air transportation.
>>> ISO9001:2008 & CE Certificate
>>> Production Flow
>>> Office & Workshop
>>> Customers' Visiting
1) What liquid do you transfer? Oil, Water, Food or Corrosive Chemical liquid, with solid particle or not, etc.
2) What's the flow or capcity (m3/h, L/m or GPM)?
3) What's the discharge head (m, feet, Mpa, bar )
