YEMOO small cold storage/cold room refrigeration unit

YEMOO small cold storage/cold room refrigeration unit

FOB Price:

US 680-2800 / Unit

Min.Order Quantity:

1 Piece/Pieces

Supply Ability:

2000 Piece/Pieces per Month

Port:

Shangai / Ningbo

Place of Origin:

Zhejiang, China (Mainland)

Payment Terms:

L/C,T/T,Western Union,MoneyGram

Brand:

YEMOO(YEMOO small cold storage/cold room refrigeration unit)

Products Model:

YMCS2-050A

Products Details
Company Profile

Quick Details

Brand Name: YEMOO(YEMOO small cold storage/cold room refrigeration unit)

Model Number: YMCS2-050A

Place of Origin: Zhejiang, China (Mainland)

Packaging & Delivery

Packaging Details: Carton/ plywood/ Wooden case
Delivery Detail: 1-7 days

Specifications

Product Description

Characteristics:

1. YEMOO small cold storage/cold room refrigeration unit for medium & high temperature (environment +12℃~ -10 ℃)

2. YEMOO small cold storage/cold room refrigeration unit for low temperature & frozen environment (-10℃ ~ -30℃)

3.Equipped with YEMOO semi-hermetic piston compressor

4. YEMOO small cold storage/cold room refrigeration unit condensers are punched by high velocity ram machine. Folded by secondary

operation:condenser coils are expanded by mechanical tube expansion to obtain high heat exchanging capacity.

5.Shell &tube water condensers use high efficient wire-whorled copper pipes which can highly increase condensers’ heat exchanging efficient. Take small volume and keep light weight All condensers are produced and inspected strictly based on “Pressure Vessel of Refrigeration equipment” to ensure products’ quality.

6.Equipped with well-known brand of refrigeration parts:

1)Normal configuration of YEMOO small cold storage/cold room refrigeration unit :filter drier, solenoid valve, double pressure controller, high & low pressure meter.

2)Standard configuration of YEMOO small cold storage/cold room refrigeration unit : vibration absorber, oil separator, filter drier, sight glass. solenoid valve, double pressure controller, high & low pressure meter.

7.We offer additional parts to meet your special requests.

Other components of YEMOO small cold storage/cold room refrigeration unit

Receiver, solenoid valve, dry filter, sight glass, higher pressure meter, low pressure meter, pressure controller, unit frame

Optional components:

Shock absorber, oil separator, gas liquid separator

If you need any further information, please feel free to contact us.

We offer customize service, OEM welcomed!

Technical Data

Technical data	Air cooling industrial chiller for medium & high temperature
Unit model	YMCS2-030A	YMCS2-040A	YMCS2-050A	YMCS2-080A	YMCS2-100A	YMCS3-150A
Compressor model	YMCS2-030	YMCS2-040	YMCS2-050	YMCS2-080	YMCS2-100	YMCS3-150
Norminal motor power (KW)	2.2	3	3.7	5.88	7.35	11
Displacement (W)	5314	6622	8745	12334	17746	25774
Refrigerant	R22
Power	380/400V-3PH-50Hz
Starting Current (A)	30-32	38-44	53-58	74-81	112-126	162-184
Max Operating current(A)	5.7	7.6	8.6	15	17.6	24.3
Crankcase heater (W)	60	60	60	120	180	180
Power of condensina fan motor	180	250	250	370	250x2	370x2
Fan motor working current	0.4	0.55	0.55	0.8	0.55x2	0.8x2
Range of Eva. Temp.(oC)	0 ~ -20 oC
Fitting environment Temp.(oC)	+0 ~ -10 oC

Dimension and installing dimension	Condenser	Receiver	Dimension			Installation Size		Connecting tube		Weight
Dimension and installing dimension	Air Cap.	Volume	A	B	C	E	F	Air Inlet	Liquid	Weight
Model	M³/h	dm³	mm	mm	mm	mm	mm	Ø(mm)	Ø(mm)	kg
YMCS2-030A	12	780	680	520	720	390	19	10	115	133
YMCS2-040A	13	670	670	600	610	380	25	12	170	139
