WZP-60 / 35KW Induction Heating Machine of Metal

WZP-60 / 35KW Induction Heating Machine of Metal

FOB Price:

US 680-3500 / Set

Min.Order Quantity:

1 Set/Sets

Supply Ability:

500 Set/Sets per Year

Port:

Shanghai, Qingdao,Tianjin, Guangzhou or as you request

Place of Origin:

Henan, China (Mainland)

Payment Terms:

L/C,D/A,D/P,T/T,Western Union,MoneyGram,paypal,cash

Brand:

yongda

Products Model:

WZP-60

Products Details
Company Profile

Quick Details

Brand Name: yongda

Model Number: WZP-60

Place of Origin: Henan, China (Mainland)

Packaging & Delivery

Packaging Details: 1. wooden cases(plywood) for packing induction heating machine of metal 2. Transport by air/sea/express/train
Delivery Detail: 3-5 days after your formal order

Specifications

WZP-60 / 35KW Induction Heating Machine of Metal

Product Description

Applications of induction heating machine of metal
1, through thermoforming all kinds of standard parts, fasteners, machinery parts, hardware tools, straight shank twist drill of hot forging, hot rolling, metal annealing. Such as: tensile steel; wire, nail wire heating; stainless steel annealed, rose type.
2, heat treatment various types of hardware tools, electric, hydraulic, pneumatic components, automotive, motorcycle parts and other mechanical parts of the surface of the metal, the hole, partial or total quenching. Such as: hammer, knife, scissors, pliers and all kinds of shafts, cams, sprockets, gears, valves, ball stud, a large machine tool guide, ductile iron quenching.
3, various types of brazing carbide blade, turning, milling, planing, reamer, diamond saw blade, serrated welding; grinding, drilling, cutting welding; brass, copper, stainless steel pot, etc. hybrid welding of metallic materials.
4, metal melting: melting gold, silver and copper.
5, other areas of plastic pipe heating cable, heating wire coating; food, beverage, pharmaceutical industry, the use of aluminum foil.

Technical parameters of WZP-60 induction heating machine of metal

Model	Work power	Output power	Oscillation frequency	Output current	Cooling water pressure	Size	Weight
WZP-60	three phase 3800V+/-10% 50-60HZ	3-35KW	10-50KHZ	6-60A	0.1MPA	generator 500×360×455mm transformer 590330650mm	41kgs, 37kgs

Model

Work power

Output power

Oscillation frequency

Output current

Cooling water pressure

Size

Weight

WZP-60

three phase 3800V+/-10% 50-60HZ

3-35KW

10-50KHZ

6-60A

0.1MPA

generator 500×360×455mm

transformer 590*330*650mm

41kgs, 37kgs

More machine model

Model	Input voltage	Input current	Oscillation frequency	Cooling water pressure
WZP-40	320-420V	2-40A	15-30KHZ	0.1MPA
WZP-60	320-420V	3-60A	15-30KHZ	0.2MPA
WZP-90	320-420V	4-90A	15-30KHZ	0.3MPA
WZP-120	320-420V	6-120A	15-30KHZ	0.3MPA
WZP-160	320-420V	6-160A	15-30KHZ	0.3MPA
WZP-200	320-420V	6-200A	15-30KHZ	0.3MPA
WZP-300	320-420V	6-300A	15-30KHZ	0.3MPA
WZP-400	320-420V	6-400A	8-15KHZ	0.3MPA
WZP-500	320-420V	6-500A	8-15KHZ	0.3MPA

Pictures of induction heating machine of metal

We are in induction heating industry exhibition

Warranty: one year guarantee

After -sale service: provide long-term technical support

Install: When you receive the machine, can easy install the machine based on our installing drawings, sketch.

Customer need prepare water hose, electric, build a water pool or buy a closed cooling tower, or industrial chiller.

We aslo can provide if you needed. Such as CNC hardening machine tool ,automatic feeding machine, infrared thermometer, industrial chiller etc. These auxiliary machines are optional.

About Us

FAQ

What’s your MOQ?	Any quantity of machine will be accepted. MOQ:1 Set
Which place your factory is located?	We are located in Shenqiu County, Zhoukou city, Henan Province ,China
How far from Beijing? I think it is more closer to Shanghai	Our factory is near both and Shanghai. We have office in Zhengzhou, we can pick up you at Zhengzhou CGO airport,and then to our factory via expressway about two hours.
We need to see some more videos for production line and also pictures of your factory, water drawing and panel drawing	Well, we have many videos show our customer’s machine working scene(Various of applications: forging,hardening, brazing, shrink fitting, melting and hot coating etc. According to your work piece processing requirements,) send you the corresponding video link or send by email. 2. Yes, we can provide you factory pictures and machine water connection and control panel details.
Do you have quality certifications?	Yes, we got the ISO9001:2000 International quality management system certification in August,2001,
How do you packing the machines?	Standard export wooden cases(plywood) Usually every set machine will be used two wooden cases: one for packing induction heating generator, one for packing transformer. Inside will be filled with plastic foam for waterproof and shockproof
More questions….?	Updating…

Contact Information

Thanks for your reading !

If you are interted in metal forging machine, please feel free to inquiry us ! We will provide you the best servcie as best as we can.

Shenqiu Yongda High Frequency Equipment Co., Ltd. was founded in 1996,which belongs to Henan high-tech enterprise ,was located in No.65, Liufu Village Liufu town, Shenqiu County, Henan ,China .
We have international trade department in Zhengzhou city. East to international airport (CGO), besides, high way, high speed rail, transport is very convenient.

We professionally dedicated to R & D, produce and sale high frequency, super audio frequency, medium frequency induction heating equipment: WGH ,WZP and KGPS series, CNC quenching machine tool and automatic feeder machine etc. We adhering to the spirit of innovation, mean while strengthening cooperation with domestic well-known universities and research institutions.

Our machine is mainly used for heating metal, induction forging, hardening, brazing, annealing, melting , shrink fit, etc. other fields.

Yongda High frequency Equipment Co.,Ltd is the leader of induction heating field and biggest full solid state induction heating equipment manufacturer in China. Our products has got CE and ISO certification and hot sale at home and abroad. Up to now, we already exported to Europe, America, and Southeast Asia etc. other regions.

Welcome everyone to visit us and negotiation business !
