Low maintenance cost induction furnace for forging steel

FOB Price:

US 5000-30000 / Set

Min.Order Quantity:

1 Set/Sets

Supply Ability:

500 Set/Sets per Year

Port:

Shanghai, Qingdao,Tianjin, Guangzhou or as you request

Place of Origin:

Henan, China (Mainland)

Payment Terms:

L/C,D/A,D/P,T/T,Western Union,MoneyGram,paypal,cash

Brand:

Yongda

Products Model:

GTR-500KW/2-4KHZ

Products Details
Company Profile

Quick Details

Brand Name: Yongda

Model Number: GTR-500KW/2-4KHZ

Place of Origin: Henan, China (Mainland)

Packaging & Delivery

Packaging Details: Wooden cases(plywood) for packing induction furnace for forging
Delivery Detail: Within 12 days after 30% advance payment

Specifications

Low maintenance cost induction furnace for forging steel

Product Description

Technical parameters of induction furnace for forging

Model	Rated power	Rated frequency (KHZ)	Temperature℃	Power consumption (KWH/T)	Work piece diameter (MM)
GTR-50KW/10KHZ	50KW	10	900-1250	350-450	4-30
GTR-100KW/8-10KHZ	100KW	8-10	900-1250	350-450	19-41
GTR-150KW/6-8KHZ	150KW	6-8	900-1250	350-450	19-41
GTR-200KW/6-8KHZ	200KW	6-8	900-1250	350-450	24-51
GTR-250KW/6-8KHZ	250KW	6-8	900-1250	350-450	24-51
GTR-300KW/2-4KHZ	300KW	2-4	900-1250	350-450	29-61
GTR-350KW/2-4KHZ	350KW	2-4	900-1250	350-450	29-61
GTR-400KW/2-4KHZ	400KW	2-4	900-1250	350-450	29-81
GTR-500KW/2-4KHZ	500KW	2-4	900-1250	350-450	39-81
GTR-600KW/1-2KHZ	600KW	1-2	900-1250	350-450	49-101
GTR-750KW/1-2KHZ	750KW	1-2	900-1250	350-450	49-101
GTR-1000KW/0.5-1KHZ	1000KW	0.5-1	900-1250	350-450	59-121

Features of medium frequency induction furnace for forging

1. Full digital control:control with high precision and high reliability

2. Voltage and current double closed-loop control system:to ensure a stable and reliable operation of the system.

3. Perfect protection system: over voltage,over current,lack of phase,lack of water, temperature is high, etc, various of protection,ensure the equipment's components will not be damaged when a fault occurs

4. High powder factor:the power and power factor of the equipment achieve to highest operating values

5. Complete extrocontrol interface:can easily achieve external temperature ect.closed-loop control

6. Power pneumatic performance 100% completely eliminate the problem of start

Advantages of induction furnace for forging

1.by detecting the rod temperature at the outlet of the induction coil, the heating power is controlled by the temperature controller device, such to control the temperature of the rod.

2.melting of rods inside the induction coil will not happen any more by the using of infrared sensor and temperature control device. The operating is eased, at the same time, repair of the induction coil is decreased greatly.

3.it is especially important and necessary to use infrared sensor when heating brass and aluminum rods of which the forging temperature and melting point is very near. The forging temperature of brass is about 700°C and melting point about 900°C, the forging temperature of aluminum is about 450-500°C and melting point about 660°C, in the continuously heating and feeding process, it is likely to happen that the rods melt inside the induction coil due to to careless of operator,. To install the infrared sensor is the only way to solve this problem.

Packaging & Shipping

Warranty: one year free replacement spare parts of induction heating power supply. provide long-terms technical support.

Our Services

1. Reply your inquiry within 24 working hours
2. Experienced engineer instruct and sales communicate with you in fluent English.
3. According to work pieces specifications, heating requirements, propose best solutions,also reference your ideas.
4. Machine details and working video link for your reference
5. Competitive price ,compare with the same industry
6. Production: strict quality standard, to produce machine and induction coils.
7. Debugging machine and only good machine will be sent.
8. Tracking goods shipping and provide bill of lading,invoice,packing list and other documents what you need
9. Provide install and technology instruction by sending drawings, email, or telephone,video.
10.If you need, will arrange one engineer to your place,instruct install machine and training operators.
11.Excess warranty period(12 months warranty), you can buy the spare parts from us with special discount price.
12.Provide long-terms technical support

Company's honor- good faith service units

FAQ

What’s your MOQ?	Any quantity of machine will be accepted. MOQ:1 Set
Which place your factory is located?	We are located in Shenqiu County, Zhoukou city, Henan Province ,China
How far from Beijing? I think it is more closer to Shanghai	Our factory is near both and Shanghai. We have office in Zhengzhou, we can pick up you at Zhengzhou CGO airport,and then to our factory via expressway about two hours.
We need to see some more videos for production line and also pictures of your factory, water drawing and panel drawing	Well, we have many videos show our customer’s machine working scene(Various of applications: forging,hardening, brazing, shrink fitting, melting and hot coating etc. According to your work piece processing requirements,) send you the corresponding video link or send by email. 2. Yes, we can provide you factory pictures and machine water connection and control panel details.
Do you have quality certifications?	Yes, we got the ISO9001:2000 International quality management system certification in August,2001,
How do you packing the machines?	Standard export wooden cases(plywood) Usually every set machine will be used two wooden cases: one for packing induction heating generator, one for packing transformer. Inside will be filled with plastic foam for waterproof and shockproof
More questions….?	Updating…

Contact Me

Shenqiu Yongda professionally manufacture induction furnace for forging. Power range : 100KW to 1500KW . The machine can heat middle and big sized steel or copper billets.

As soon as you tell us your work pieces specifications , we can recommend you a suitable machine model and design best induction forging furnace for you.

Thanks for your reading ! Welcome to contact us !

Shenqiu Yongda High Frequency Equipment Co., Ltd. was founded in 1996,which belongs to Henan high-tech enterprise ,was located in No.65, Liufu Village Liufu town, Shenqiu County, Henan ,China .
We have international trade department in Zhengzhou city. East to international airport (CGO), besides, high way, high speed rail, transport is very convenient.

We professionally dedicated to R & D, produce and sale high frequency, super audio frequency, medium frequency induction heating equipment: WGH ,WZP and KGPS series, CNC quenching machine tool and automatic feeder machine etc. We adhering to the spirit of innovation, mean while strengthening cooperation with domestic well-known universities and research institutions.

Our machine is mainly used for heating metal, induction forging, hardening, brazing, annealing, melting , shrink fit, etc. other fields.

Yongda High frequency Equipment Co.,Ltd is the leader of induction heating field and biggest full solid state induction heating equipment manufacturer in China. Our products has got CE and ISO certification and hot sale at home and abroad. Up to now, we already exported to Europe, America, and Southeast Asia etc. other regions.
