DZ X Yonjou Diaphragm Metering Hydraulic Piston Pump

FOB Price:

US 199-599 / Set

Min.Order Quantity:

10 Set/Sets

Supply Ability:

2000 Set/Sets per Month

Port:

Ningbo, Shanghai

Place of Origin:

Zhejiang, China (Mainland)

Payment Terms:

L/C,T/T,Western Union

Brand:

YONJOU

Products Model:

DZ-X

Products Details
Company Profile

Quick Details

Brand Name: YONJOU

Model Number: DZ-X

Place of Origin: Zhejiang, China (Mainland)

Packaging & Delivery

Packaging Details: standard export wood case packing per hydraulic piston pump
Delivery Detail: --

Specifications

DZ-X Metering Pumps
1.Simple Plug pump head Construction
2.Precise metering
3.Anti-abrasion plug& seal
4. Anti-corrosive

Hydraulic Piston Pump

Summary

This series products work theory features is mechanical diaphragm metering pumps work by turbine and worm through motor drivenfor low pressure fluid meteringapplications.

Diaphragm metering pumps use the flexible diaphragm replaced piston, it driven by the drive mechanism for reciprocating movement to change the pump chamber volume, also with the action of pump inlet&Outlet valve to finish liquid exaust and drainage.

Diaphragm metering pump can according to the needs of variety of processes, the flow capacity can be regulate in the range of 0-100% , quantitative conveying no solidparticles of corrosive or non-corrosive liquids.

The pump head materials with a variety of choice as like PPH, PTFE, PVC, PVDF, RPP, SS304, 316,316 L.
The diaphragm of diaphragm metering pump can completely isolate the liquid flow and driven lubricant mechanism. Using high-technical design and uses the latest new type of PTFE and rubber composite

diaphragm, can resist strong corrosion and greatly extends the diaphragm life.

Main Specification parameter

1. Flow capacity: 0.8~18000liter/hour

2. Max Pressure: 50Mpa

3. Metering Precise: +_1%

4.Liquid Viscosity: 0-800mm2/s

5. Liquid temperature: Below 450°c
